Linkage Carrier/Engine Mounting Bolts
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2079347 Linkage carrier | Linkage carrier Pair | 1 | $115.51 | Obsolete | View Details |
| 2 | 3330220-T0301 Screw, Torx | Screw, Torx » 52431 M12 x 61mm | 2 | $4.27 | Obsolete | View Details |
| 3 | T3150317 Bolt, HHF, M12 x 85, Silver | Bolt, HHF, M12 x 85, Silver » 52431 M12 x 81mm | 2 | $6.14 | Backorder — Late August 2026 | 2 |
| 3 | T3150304 Bolt, Hex HD, Flgd, M12x85 | Bolt, Hex HD, Flgd, M12x85 52432 » M12 x 81mm Black | 2 | $3.43 | Obsolete | View Details |
| 4 | T3151013 Bolt, HHF , M12 x 1.25 x 150, 10.9, Slv | Bolt, HHF , M12 x 1.25 x 150, 10.9, Slv » 52431 M12 x 148mm | 1 | $21.41 | Available to order | 1 |
| 5 | T3334680 Bolt, HHF, M12 x 119, Slv | Bolt, HHF, M12 x 119, Slv » 52431 | 1 | $8.33 | Available to order | 1 |
| 5 | 3330251-T0301 Screw, Torx, M12 x 119 | Screw, Torx, M12 x 119 52432 » M12 x 119mm Black | 1 | $6.14 | Unavailable | 1 |
| 6 | T3550614 Washer, 12 x 23 x 2 | Washer, 12 x 23 x 2 4 Cyl | 3 | $0.97 | Available to order | 3 |
| 7 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 | 4 | $6.07 | Available to order | 4 |
| 9 | 2079213-T0301 Spacer tube | Spacer tube Linkage carrier | 1 | $13.57 | Obsolete | View Details |
