Ignition Switch & Lock Set
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2500795 Lock set | Lock set * PART NO LONGER AVAILABLE * Includes 2 keys » 86626 - Pacific Blue » 86426 - Platinum » 86375 - British Racing Green | 1 | $525.58 | Obsolete | View Details |
| 1 | T2500875 Lock set | Lock set Includes 2 keys - US CAL - All Vins All Other Markets 86627 » Blue All Other Markets 86427 » | 1 | $436.78 | Obsolete | View Details |
| 2 | 2500034-T0301 Key, Uncut | Key, Uncut Key blank to be cut by dealer | 1 | $22.67 | Available to order | 1 |
| 2 | T2500076 Key, Cut | Key, Cut Customer must supply key number with order | 1 | $77.56 | Out of Stock | Notify Me |
| 3 | T3330327 Bolt, Shear, M6 x 22, Enc | Bolt, Shear, M6 x 22, Enc | 2 | $5.58 | Available to order | 2 |
| 4 | 2500038-T0301 Switch/Lock Assy Ign | Switch/Lock Assy Ign Includes 2 keys | 1 | $227.01 | Out of Stock | Notify Me |
| 5 | 2400004-T0301 Fuel filler cap | Fuel filler cap Not US CAL, Includes 2 Keys » 86626 - Pacific Blue » 86426 - Platinum » 86375 - British Racing Green | 1 | $183.60 | Obsolete | View Details |
| 5 | T2400032 Fuel filler cap | Fuel filler cap US CAL, Includes 2 Keys, All Vins All Other Markets 86627 » Blue All Other Markets 86427 » | 1 | $183.60 | Obsolete | View Details |
| 6 | T2505000 Actuating lever | Actuating lever | 1 | $11.82 | Obsolete | View Details |
| 7 | T2503000 Seat lock | Seat lock Includes 2 keys | 1 | $117.84 | Obsolete | View Details |
| 8 | 2080101-T0301 Striker | Striker | 1 | $13.94 | Available to order | 1 |
| 9 | T3330184 Screw, C'sunk Tx, M6 x 25, Slv | Screw, C'sunk Tx, M6 x 25, Slv | 2 | $1.36 | Available to order | 2 |
| 10 | T3350650 Screw | Screw M6 x 20mm | 2 | $9.96 | Obsolete | View Details |
| 11 | T2070732 Security plate | Security plate | 1 | $2.53 | Obsolete | View Details |
| 12 | T3351021 Nut, Captive, M6, Slv | Nut, Captive, M6, Slv | 2 | $1.91 | Available to order | 2 |
| 13 | T3551283 Washer, M10, 10.5x18x1.6, Slv | Washer, M10, 10.5x18x1.6, Slv » 40190 | 2 | $2.14 | Available to order | 2 |
| 14 | T2500114 Lock set | Lock set Panniers | 2 | $50.09 | Available to order | 2 |
| 15 | T3350066 Nut | Nut M22 | 2 | $5.05 | Available to order | 2 |
| 16 | T2500296 Kit, Lock, Fascia, Pocket | Kit, Lock, Fascia, Pocket Includes 2 keys. | 1 | $46.48 | Obsolete | View Details |
