Ignition System
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1290048 Ignition coil (4 Cyl) | Ignition coil (4 Cyl) 4 Cyl | 2 | $263.76 | Available to order | 2 |
| 1 | T1290046 Ignition coil | Ignition coil 3 Cyl | 3 | $263.76 | Available to order | 3 |
| 2 | 1290014-T0301 Ignition cable | Ignition cable Set 4 Cyl | 1 | $182.47 | Available to order | 1 |
| 2 | 1290013-T0301 Ignition cable | Ignition cable Set 3 Cyl | 1 | $169.19 | Available to order | 1 |
| 3 | T1290024 Spark Plug, DPR8EA-9 | Spark Plug, DPR8EA-9 NGK DPR 9 EA-9 4 Cylinder Standard | 4 | $7.34 | Available to order | 4 |
| 4 | T3338989 Screw, But/Hd, M5 x 20, S/S | Screw, But/Hd, M5 x 20, S/S » 67827 4 Cyl | 4 | $6.77 | Available to order | 4 |
| 4 | T3330728 Screw, Pan/Hd, Tx, M5 x 16, Enc | Screw, Pan/Hd, Tx, M5 x 16, Enc 67828 » 4 Cyl | 4 | $0.97 | Available to order | 4 |
| 5 | T1290022 Sensor | Sensor » ENG NO 56144 | 1 | $263.76 | Available to order | 1 |
| 6 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 2 | $1.40 | Available to order | 2 |
| 7 | T3050161 Screw, Cap/HD. M8 x 20, Raw | Screw, Cap/HD. M8 x 20, Raw | 1 | $0.97 | Out of Stock | Notify Me |
| 8 | T1290115 Rotor | Rotor 4 Cyl | 1 | $29.30 | Obsolete | View Details |
| 8 | T1290110 Rotor | Rotor ** Part No Longer Available ** | 1 | $32.16 | Obsolete | View Details |
| 9 | 1100039-T0301 Clamping piece | Clamping piece | 1 | $15.14 | Available to order | 1 |
| 10 | 1290012-T0301 Mounting strap | Mounting strap | 1 | $10.05 | Obsolete | View Details |
| 11 | T1290070 Igniter | Igniter » 45787 4 Cyl | 1 | $396.11 | Backorder — Late August 2026 | 1 |
| 11 | T1290072 Igniter | Igniter 45788 » 4 Cyl | 1 | $492.91 | Available to order | 1 |
| 11 | T1290060 Igniter | Igniter » 45787 3 Cyl | 1 | $336.73 | Obsolete | View Details |
| 11 | T1290066 Igniter | Igniter 45788 » 3 Cyl | 1 | $351.53 | Obsolete | View Details |
| 11 | T1290075 Igniter | Igniter » 45787 3 Cyl US Cal ONLY | 1 | $336.73 | Obsolete | View Details |
| 11 | T1290083 Igniter | Igniter 45788 » 3 Cyl US Cal ONLY | 1 | $336.73 | Obsolete | View Details |
| 12 | T3555023 Washer, 5.3 x 18 x 1.6 | Washer, 5.3 x 18 x 1.6 » 67827 4 Cyl | 4 | $1.27 | Available to order | 4 |
| 13 | T3550082 Washer rubber | Washer rubber » 67827 4 Cyl | 4 | $0.75 | Available to order | 4 |
