Rear Lamps
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2700157 Tail lamp | Tail lamp | 1 | $125.85 | Obsolete | View Details |
| 2 | T2700158 Tail lamp lens | Tail lamp lens | 1 | $62.90 | Obsolete | View Details |
| 3 | T2700159 Backplate | Backplate | 1 | $35.32 | Obsolete | View Details |
| 4 | T2700197 Mounting | Mounting M5 | 3 | $14.27 | Available to order | 3 |
| 5 | T2700196 Screw | Screw | 2 | $1.06 | Obsolete | View Details |
| 6 | T2700493 Nut & Washer Assy, M5, Slv | Nut & Washer Assy, M5, Slv | 3 | $1.79 | Available to order | 3 |
| 7 | 2700054-T0301 Bulb, 12v 21w/5w | Bulb, 12v 21w/5w | 2 | $6.65 | Available to order | 2 |
| 8 | T2070990 Bracket | Bracket | 1 | $13.61 | Backorder — Late August 2026 | 1 |
| 9 | T2700198 Harness | Harness Rear lamp | 1 | $31.39 | Available to order | 1 |
| 10 | T3350029 Square nut | Square nut M8 | 2 | $8.09 | Available to order | 2 |
