Crankcase Fixings 4 Cylinder » 12657
Parts (9)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 3330024-T0301 Screw, Torx | Screw, Torx M8 x 155mm - PART NO LONGER AVAILABLE | 5 | $6.46 | Obsolete | View Details |
| 2 | 3330021-T0301 Screw, Torx | Screw, Torx M8 x 80mm | 2 | $5.60 | Available to order | 2 |
| 3 | T3330121 Screw, Torx | Screw, Torx PART NO LONGER AVAILABLE - M8 x 105mm | 6 | $1.70 | Obsolete | View Details |
| 4 | 3330020-T0301 Screw, Torx | Screw, Torx M8 x 65mm | 1 | $8.81 | Obsolete | View Details |
| 5 | 3330023-T0301 Screw, Torx | Screw, Torx M8 x 130mm | 1 | $10.00 | Obsolete | View Details |
| 6 | 3330031-T0301 Screw,torx | Screw,torx M6 x 130mm | 3 | $4.40 | Obsolete | View Details |
| 7 | T3331299 Screw, Pan/HD, Tx, M6 x 40, Slv | Screw, Pan/HD, Tx, M6 x 40, Slv M6 x 40mm | 8 | $3.70 | Available to order | 8 |
| 8 | 3330027-T0301 Screw, Torx | Screw, Torx M6 x 140mm | 3 | $11.08 | Obsolete | View Details |
| 9 | T3331041 Screw, Pan/Hd, Tx, M6 x 25, Enc | Screw, Pan/Hd, Tx, M6 x 25, Enc | 1 | $1.06 | Available to order | 1 |
