Headlamp
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2700140-T0301 Headlight Assembly | Headlight Assembly LH dip UK, NZ, AU, JP, ZA, CY, HK, MY | 1 | $258.86 | Obsolete | View Details |
| 1 | T2700480 Headlight Assembly | Headlight Assembly RH dip DE,ES,IT,PT,NL,CH,GR,AR,BR,FR,CA,US | 1 | $258.86 | Obsolete | View Details |
| 2 | T2700485 Lens | Lens RH dip DE,ES,IT,PT,NL,CH,GR,AR,BR,FR,CA,US | 1 | $110.96 | Obsolete | View Details |
| 3 | T2700001 Bulb, H4 60/55W, 12V, Type 1, Clear | Bulb, H4 60/55W, 12V, Type 1, Clear | 1 | $17.69 | Available to order | 1 |
| 3 | 2700101-T0301 Bulb halogen | Bulb halogen FR - Yellow bulb (use White bulb after January 1993) | 1 | $83.49 | Obsolete | View Details |
| 4 | 2700061-T0301 Harness | Harness | 1 | $41.74 | Obsolete | View Details |
| 5 | T2700938 Bulb, W5W, 5W, 12V, Clear | Bulb, W5W, 5W, 12V, Clear | 1 | $4.30 | Available to order | 1 |
| 6 | 2700110-T0301 Socket | Socket | 2 | $5.60 | Available to order | 2 |
| 7 | 2700115-T0301 Adjuster screw | Adjuster screw | 2 | $2.63 | Obsolete | View Details |
| 8 | 2700105-T0301 Ball | Ball | 1 | $10.32 | Obsolete | View Details |
| 9 | 2700125-T0301 Clamp | Clamp | 1 | $8.41 | Obsolete | View Details |
| 10 | 3330415-T0301 Screw | Screw | 2 | $1.13 | Available to order | 2 |
| 11 | 2700013-T0301 Mounting bracket | Mounting bracket | 1 | $11.17 | Obsolete | View Details |
| 12 | T3021200 Grommet, Dia 14x4, Panel | Grommet, Dia 14x4, Panel | 4 | $3.17 | Available to order | 4 |
| 13 | T3010701 Flanged Sleeve, 6.4 x 10 x 14.5 | Flanged Sleeve, 6.4 x 10 x 14.5 | 4 | $5.30 | Available to order | 4 |
| 14 | 3660070-T0301 Foam | Foam | 1 | $14.16 | Out of Stock | Notify Me |
