Triumph Trophy Bodywork - Rear Side Panels & Seat — OEM Parts Diagram | Triumph Waukesha

Bodywork - Rear Side Panels & Seat

Bodywork Fixings →

Parts (80)

#	Part Number	Description	Qty	Price	Status
1	T2300675 Seat	Seat Black	1	$677.96	Obsolete	View Details
1	T2300665 Seat	Seat Black JP	1	$748.17	Out of Stock	Notify Me
2	2305120-T0301 Side panel lh	Side panel lh » 3871 Charcoal Grey 3 & 4 Cyl	1	$305.83	Obsolete	View Details
2	2305119-T0301 Side panel lh	Side panel lh 3872 » Charcoal Grey 4 Cyl	1	$305.83	Obsolete	View Details
2	2305419-T0301 Side panel lh	Side panel lh 3872 » Charcoal Grey 3 Cyl	1	$336.22	Out of Stock	Notify Me
2	2305130-T0301 Side panel lh	Side panel lh Burgundy 4 Cyl	1	$305.83	Obsolete	View Details
2	2305430-T0301 Side panel lh	Side panel lh Burgundy 3 Cyl	1	$305.83	Obsolete	View Details
2	2305132-T0301 Side panel lh	Side panel lh » 4901 British Racing Green 4 Cyl	1	$305.83	Obsolete	View Details
2	2305443-T0301 Side panel lh	Side panel lh 4902 » British Racing Green 4 Cyl	1	$305.83	Obsolete	View Details
2	2305432-T0301 Side panel lh	Side panel lh » 4901 British Racing Green 3 Cyl	1	$305.83	Obsolete	View Details
2	2305445-T0301 Side panel lh	Side panel lh 4902 » British Racing Green 3 Cyl	1	$305.83	Obsolete	View Details
2	2305133-T0301 Side panel lh	Side panel lh Oxford Blue 4 Cyl	1	$305.83	Obsolete	View Details
2	2305433-T0301 Side panel lh	Side panel lh Oxford Blue 3 Cyl	1	$305.83	Obsolete	View Details
2	2305439-T0301 Side panel lh	Side panel lh Caspian Blue 4 Cyl	1	$305.83	Obsolete	View Details
2	2305441-T0301 Side panel lh	Side panel lh Caspian Blue 3 Cyl	1	$305.83	Obsolete	View Details
2	2305435-T0301 Side panel lh	Side panel lh Candy Apple Red 4 Cyl	1	$305.83	Obsolete	View Details
2	2305437-T0301 Side panel lh	Side panel lh Candy Apple Red 3 Cyl	1	$305.83	Obsolete	View Details
2	2305121-T0301 Side panel lh	Side panel lh Caribbean Blue	1	$305.83	Obsolete	View Details
2	2305122-T0301 Side panel lh	Side panel lh Lancaster Red	1	$305.83	Obsolete	View Details
2	2305126-T0301 Side panel lh	Side panel lh Caribbean Blue DE First edition	1	$305.83	Obsolete	View Details
2	T2305456-KD Side panel lh	Side panel lh Nightshade 4 Cyl	1	$305.83	Obsolete	View Details
2	T2305461-KD Side panel lh	Side panel lh Nightshade 3 Cyl	1	$305.83	Obsolete	View Details
3	2305150-T0301 Side panel rh	Side panel rh » 3871 Charcoal Grey 3 & 4 Cyl	1	$305.83	Obsolete	View Details
3	2305149-T0301 Side panel rh	Side panel rh 3872 » Charcoal Grey 4 Cyl	1	$305.83	Obsolete	View Details
3	2305449-T0301 Side panel rh	Side panel rh 3872 » Charcoal Grey 3 Cyl	1	$305.83	Obsolete	View Details
3	2305160-T0301 Side panel rh	Side panel rh Burgundy 4 Cyl	1	$305.83	Obsolete	View Details
3	2305460-T0301 Side panel rh	Side panel rh Burgundy 3 Cyl	1	$305.83	Obsolete	View Details
3	2305162-T0301 Side panel rh	Side panel rh » 4901 British Racing Green 4 Cyl	1	$305.83	Obsolete	View Details
3	2305444-T0301 Side panel rh	Side panel rh 4902 » British Racing Green 4 Cyl	1	$305.83	Obsolete	View Details
3	2305462-T0301 Side panel rh	Side panel rh » 4901 British Racing Green 3 Cyl	1	$305.83	Obsolete	View Details
3	2305446-T0301 Side panel rh	Side panel rh 4902 » British Racing Green 3 Cyl	1	$305.83	Obsolete	View Details
3	2305163-T0301 Side panel rh	Side panel rh Oxford Blue 4 Cyl	1	$305.83	Obsolete	View Details
3	2305463-T0301 Side panel rh	Side panel rh Oxford Blue 3 Cyl	1	$305.83	Obsolete	View Details
3	2305440-T0301 Side panel rh	Side panel rh Caspian Blue 4 Cyl	1	$305.83	Obsolete	View Details
3	2305442-T0301 Side panel rh	Side panel rh Caspian Blue 3 Cyl	1	$305.83	Obsolete	View Details
3	2305436-T0301 Side panel rh	Side panel rh Candy Apple Red 4 Cyl	1	$305.83	Obsolete	View Details
3	2305438-T0301 Side panel rh	Side panel rh Candy Apple Red 3 Cyl	1	$305.83	Obsolete	View Details
3	2305151-T0301 Side panel rh	Side panel rh Caribbean Blue	1	$305.83	Obsolete	View Details
3	2305152-T0301 Side panel rh	Side panel rh Lancaster Red	1	$305.83	Obsolete	View Details
3	2305156-T0301 Side panel rh	Side panel rh Caribbean Blue DE First edition	1	$305.83	Obsolete	View Details
3	T2305459-KD Side panel rh	Side panel rh Nightshade 4 Cyl	1	$305.83	Obsolete	View Details
3	T2305464-KD Side panel rh	Side panel rh Nightshade 3 Cyl	1	$305.83	Obsolete	View Details
4	2303180-T0301 End cap	End cap » 3871 Charcoal Grey	1	$239.57	Out of Stock	Notify Me
4	2303171-T0301 End cap	End cap 3872 » Charcoal Grey	1	$239.57	Out of Stock	Notify Me
4	2303170-T0301 End cap	End cap Burgundy	1	$200.62	Obsolete	View Details
4	2303172-T0301 End cap	End cap » 4901 British Racing Green	1	$200.62	Obsolete	View Details
4	2303176-T0301 End cap	End cap 4902 » British Racing Green	1	$200.62	Obsolete	View Details
4	2303173-T0301 End cap	End cap Oxford Blue	1	$200.62	Obsolete	View Details
4	2303175-T0301 End cap	End cap Caspian Blue	1	$200.62	Obsolete	View Details
4	2303174-T0301 End cap	End cap Candy Apple Red	1	$200.62	Obsolete	View Details
4	2303181-T0301 End cap	End cap Caribbean Blue	1	$200.62	Obsolete	View Details
4	2303182-T0301 End cap	End cap Lancaster Red	1	$200.62	Obsolete	View Details
4	T2303193-KD End cap	End cap Nightshade	1	$200.62	Obsolete	View Details
5	2300092-T0301 Grab rail	Grab rail Charcoal Grey	1	$251.78	Obsolete	View Details
5	2300078-T0301 Grab rail	Grab rail Burgundy - Part No Longer Available	1	$251.78	Obsolete	View Details
5	T2300236-HA Grab rail	Grab rail » 16921 British Racing Green	1	$220.77	Obsolete	View Details
5	2300072-T0301 Grab rail	Grab rail Oxford Blue	1	$251.78	Obsolete	View Details
5	T2300444 Grab rail	Grab rail Caspian Blue	1	$239.57	Backorder — Late August 2026	1
5	2300083-T0301 Grab rail	Grab rail Candy Apple Red	1	$251.78	Obsolete	View Details
5	2300070-T0301 Grab rail	Grab rail Caribbean Blue	1	$251.78	Obsolete	View Details
5	2300080-T0301 Grab rail	Grab rail Lancaster Red	1	$251.78	Obsolete	View Details
5	T2300236-KD Grab rail	Grab rail Nightshade	1	$251.78	Obsolete	View Details
6	3900060-T0301 Label	Label PART NO LONGER AVAILABLE - 16921 » Daily checks UK, NZ, AU, ZA, GR, CY, HK, MY, SE	1	$4.99	Obsolete	View Details
6	3910060-T0301 Label	Label 16921 » Daily checks CH, DE	1	$4.18	Obsolete	View Details
6	3901060-T0301 Label	Label 16921 » Daily checks NL	1	$1.13	Out of Stock	Notify Me
6	3902060-T0301 Label	Label 16921 » Daily checks FR	1	$6.84	Obsolete	View Details
6	3903060-T0301 Label	Label 16921 » Daily checks IT	1	$6.84	Obsolete	View Details
6	3904060-T0301 Label	Label 16921 » Daily checks AR, ES	1	$6.84	Obsolete	View Details
6	3906060-T0301 Label	Label 16921 » Daily checks JP	1	$6.84	Obsolete	View Details
6	3907060-T0301 Label	Label 16921 » Daily checks BR, PT	1	$6.84	Obsolete	View Details
6	T3900152 Label, Daily Safety Checks	Label, Daily Safety Checks Daily checks CA ONLY » 16921, All markets 16922 »	1	$5.69	Backorder — Late August 2026	1
7	2300165-T0301 Knee pad upper lh	Knee pad upper lh » 4902	1	$16.56	Out of Stock	Notify Me
8	2300166-T0301 Knee pad upper rh	Knee pad upper rh 4902 »	1	$16.56	Out of Stock	Notify Me
9	2300167-T0301 Knee pad lower lh	Knee pad lower lh 4902 »	1	$16.56	Out of Stock	Notify Me
10	2300168-T0301 Knee pad lower rh	Knee pad lower rh 4902 »	1	$16.56	Out of Stock	Notify Me
11	T3350300 Nut, M6 x 1.0, Slv	Nut, M6 x 1.0, Slv 4902 »	8	$0.94	Available to order	8 Ships within 3–7 business days
12	3550014-T0301 Washer	Washer Part No Longer Available	8	$0.96	Obsolete	View Details
13	3660120-T0301 Foam	Foam » 4901 Rear lamp	1	$6.83	Obsolete	View Details
13	3660123-T0301 Foam	Foam 4902 » Rear lamp	1	$6.83	Obsolete	View Details
14	T3900021 Label	Label 16921 » Battery breather pipe UK, NZ, AU, ZA, GR, CY, HK, MY, SE	1	$2.85	Out of Stock	Notify Me
