Electrical Equipment
Parts (57)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2501910 Main Harness | Main Harness | 1 | $806.86 | Available to order | 1 |
| 2 | T2502450 Battery | Battery All Markets Except BR/EF/ER/GR | 1 | $144.37 | Available to order | 1 |
| 2 | T2504604 Spares Kit, Battery | Spares Kit, Battery BR Only | 1 | $155.31 | Backorder — Late September 2026 | 1 |
| 2 | T2506723 Kit, Battery, EU, YTX20L-BS | Kit, Battery, EU, YTX20L-BS EF/ER/GR Markets Only | 1 | $155.24 | Out of Stock | Notify Me |
| 2 | T2502376 Battery Multipack (10) | Battery Multipack (10) All Markets Except BR (10 x T2502450) | 1 | $1483.76 | Out of Stock | Notify Me |
| 3 | T2501915 Moulding, Battery Tray | Moulding, Battery Tray | 1 | $36.29 | Obsolete | View Details |
| 4 | T3010061 Flanged Sleeve, M6 x 9 x 3.25 | Flanged Sleeve, M6 x 9 x 3.25 | 3 | $7.68 | Available to order | 3 |
| 5 | T3330334 Screw, Tx, Pan/Hd, M6 x 16, Slv | Screw, Tx, Pan/Hd, M6 x 16, Slv | 3 | $2.79 | Available to order | 3 |
| 6 | T1310008 Starter Solenoid Assy | Starter Solenoid Assy | 1 | $71.82 | Available to order | 1 |
| 7 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 | 3 | $0.71 | Available to order | 3 |
| 8 | T1290088 Sensor, Air Temperature | Sensor, Air Temperature | 1 | $63.55 | Available to order | 1 |
| 9 | T3331414 Screw, S/Tap, Tx, 5 x 16 | Screw, S/Tap, Tx, 5 x 16 | 1 | $1.61 | Available to order | 1 |
| 10 | T3350129 Nut, Captive, M5 | Nut, Captive, M5 | 1 | $3.61 | Available to order | 1 |
| 11 | T2500990 Moulding, Battery Cover | Moulding, Battery Cover | 1 | $27.13 | Available to order | 1 |
| 12 | T2501740 Battery Strap | Battery Strap | 1 | $10.61 | Available to order | 1 |
| 13 | T2500103 Horn Assy, Low-Tone | Horn Assy, Low-Tone | 1 | $42.27 | Available to order | 1 |
| 14 | T3205156 Bolt, HHF, Lghtd, M8 x 16, Slv | Bolt, HHF, Lghtd, M8 x 16, Slv | 1 | $1.73 | Available to order | 1 |
| 15 | T2507050 Moulding, ECU Bracket | Moulding, ECU Bracket | 1 | $5.97 | Available to order | 1 |
| 16 | T3330726 Screw, Btn/Hd, M6 x 12, Slv | Screw, Btn/Hd, M6 x 12, Slv | 2 | $4.70 | Available to order | 2 |
| 17 | T1290975 Air Pressure Sensor | Air Pressure Sensor | 1 | $139.14 | Available to order | 1 |
| 18 | T3202304 Bolt, RHHF, M6 x 20, Slv | Bolt, RHHF, M6 x 20, Slv | 3 | $5.65 | Available to order | 3 |
| 19 | T2507727 Relay, Normally Open | Relay, Normally Open | 6 | $20.87 | Available to order | 6 |
| 20 | T2507728 Relay, Changeover | Relay, Changeover | 3 | $19.19 | Available to order | 3 |
| 21 | T2501931 Moulding, Harness Bracket | Moulding, Harness Bracket | 1 | $26.60 | Available to order | 1 |
| 22 | T3700201 Clip, Edge Type, Single | Clip, Edge Type, Single | 1 | $4.38 | Available to order | 1 |
| 23 | T3701098 Firtree, Dia 5 x 18 | Firtree, Dia 5 x 18 | 4 | $5.58 | Available to order | 4 |
| 24 | T3700096 P Clip, Dia 15.9, Plastic, Blk | P Clip, Dia 15.9, Plastic, Blk | 1 | $5.24 | Backorder — Late September 2026 | 1 |
| 25 | T2504511 S-Clip | S-Clip | 5 | $10.95 | Available to order | 5 |
| 26 | T3700233 Clip, Brake Hose | Clip, Brake Hose | 1 | $6.27 | Available to order | 1 |
| 27 | T2500888 Bracket, Connectors, LHS | Bracket, Connectors, LHS | 1 | $7.48 | Available to order | 1 |
| 28 | T3700182 Clip, Omega, 18mm x 14mm | Clip, Omega, 18mm x 14mm | 2 | $4.38 | Available to order | 2 |
| 29 | T3330892 Bolt, RHHF, M5 x 15, S5041 | Bolt, RHHF, M5 x 15, S5041 | 2 | $1.21 | Backorder — Early October 2026 | 2 |
| 30 | T3700196 Wire Clip, 4mm | Wire Clip, 4mm | 1 | $3.14 | Available to order | 1 |
| 31 | T3701010 Clip, Cable, Dia 21mm | Clip, Cable, Dia 21mm | 2 | $4.38 | Out of Stock | Notify Me |
| 32 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 3 | $1.84 | Available to order | 3 |
| 33 | T2501920 Starter Lead | Starter Lead | 1 | $69.05 | Available to order | 1 |
| 34 | T2502504 Lead, Battery, Positive/Negative | Lead, Battery, Positive/Negative | 1 | $11.21 | Available to order | 1 |
| 35 | T2502405 Switch, Fall Detection | Switch, Fall Detection | 1 | $77.49 | Available to order | 1 |
| 36 | T3551066 Washer, 4.3 x 12.0 x 1.0 | Washer, 4.3 x 12.0 x 1.0 | 2 | $1.73 | Out of Stock | Notify Me |
| 37 | T3330390 Screw, H/Hd, M4 x 25, Slv, Enc | Screw, H/Hd, M4 x 25, Slv, Enc | 2 | $2.91 | Available to order | 2 |
| 38 | T3700091 Clip Cable | Clip Cable | 4 | $1.21 | Available to order | 4 |
| 39 | T3700072 Cable Clip, Dia 15-16mm BK | Cable Clip, Dia 15-16mm BK | 1 | $4.38 | Available to order | 1 |
| 40 | T3700193 Clip, Double, Firtree | Clip, Double, Firtree | 1 | $1.21 | Available to order | 1 |
| 41 | T3700257 Cable Tie, Hook & Loop, 152 | Cable Tie, Hook & Loop, 152 | 1 | $2.40 | Available to order | 1 |
| 42 | T2505075 Socket, Auxillary Power | Socket, Auxillary Power | 1 | $58.76 | Available to order | 1 |
| 43 | T3550211 Washer, Plastic, M18 | Washer, Plastic, M18 | 1 | $3.54 | Available to order | 1 |
| 44 | T2502429 Bracket, Fall Detect Mount | Bracket, Fall Detect Mount | 1 | $24.73 | Available to order | 1 |
| 46 | T2504512 S Clip, 3.5 - 4.5 | S Clip, 3.5 - 4.5 | 1 | $8.71 | Available to order | 1 |
| 47 | T2503577 Engine Subharness | Engine Subharness | 1 | $95.18 | Available to order | 1 |
| 48 | T2501069 Moulding, Crankcase Tidy | Moulding, Crankcase Tidy | 1 | $11.21 | Backorder — Late September 2026 | 1 |
| 49 | T3205065 Bolt, HHF, Lghtd, M6 x 20, Enc | Bolt, HHF, Lghtd, M6 x 20, Enc | 2 | $5.97 | Available to order | 2 |
| 50 | T2501305 Fuse, Mini, 5A | Fuse, Mini, 5A | 1 | $5.05 | Available to order | 1 |
| 51 | T2501310 Fuse, Mini, 10A | Fuse, Mini, 10A | 8 | $5.05 | Available to order | 8 |
| 52 | T2501315 Fuse, Mini, 15A | Fuse, Mini, 15A | 4 | $5.05 | Available to order | 4 |
| 53 | T2501320 Fuse, Mini, 20A | Fuse, Mini, 20A | 6 | $5.05 | Available to order | 6 |
| 55 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 1 | $0.95 | Available to order | 1 |
| 56 | T3010062 Flanged Sleeve, M6 x 7.8 x 2.85 | Flanged Sleeve, M6 x 7.8 x 2.85 | 2 | $7.60 | Available to order | 2 |
