Frame
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2073419 Main Frame Assy, World | Main Frame Assy, World | 1 | $2922.21 | Out of Stock | Notify Me |
| 1 | T2073431 Main Frame Assy, Canada | Main Frame Assy, Canada | 1 | $2922.21 | Out of Stock | Notify Me |
| 1 | T2073420 Main Frame Assy, USA & Brazil | Main Frame Assy, USA & Brazil | 1 | $2922.21 | Out of Stock | Notify Me |
| 2 | T2071980 Adjuster, Frame, M12 | Adjuster, Frame, M12 | 3 | $9.78 | Out of Stock | Notify Me |
| 3 | T3100020 Stud, M6 | Stud, M6 | 7 | $2.10 | Available to order | 7 |
| 4 | T2082084 Pin, Spring Retainer | Pin, Spring Retainer ** Part No Longer Available ** | 1 | $9.92 | Obsolete | View Details |
| 5 | T2056500 Bush, Rubber Mount, 10.2 x 27 x 32 | Bush, Rubber Mount, 10.2 x 27 x 32 | 1 | $18.50 | Available to order | 1 |
| 6 | T3150317 Bolt, HHF, M12 x 85, Silver | Bolt, HHF, M12 x 85, Silver | 2 | $6.14 | Backorder — Late August 2026 | 2 |
| 7 | T3151021 Bolt, HHF, M12 x 55, 10.9, Slv | Bolt, HHF, M12 x 55, 10.9, Slv | 2 | $6.14 | Available to order | 2 |
| 8 | T3150143 Bolt, HHF, M12 x 282,10.9,Slv | Bolt, HHF, M12 x 282,10.9,Slv | 2 | $21.41 | Available to order | 2 |
| 9 | T3501795 Washer, M12, OD26, Hardened, Slv | Washer, M12, OD26, Hardened, Slv | 4 | $2.25 | Backorder — Late August 2026 | 4 |
| 10 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 | 4 | $6.07 | Available to order | 4 |
