Cooling System
Parts (36)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2108001 Water pump assy | Water pump assy | 1 | $196.00 | Obsolete | View Details |
| 2 | T2108008 Seal | Seal | 1 | $4.50 | Obsolete | View Details |
| 3 | T3600300 O ring | O ring | 1 | $8.91 | Obsolete | View Details |
| 4 | T3330105 Screw,torx | Screw,torx M6 x 75mm | 1 | $2.95 | Available to order | 1 |
| 5 | T3330107 Screw,torx | Screw,torx ** Part No Longer Available ** | 1 | $2.78 | Obsolete | View Details |
| 6 | T2100806 Hose | Hose Pump to Block | 1 | $197.17 | Available to order | 1 |
| 7 | T2102111 Hose Clip, 12-20, Bright | Hose Clip, 12-20, Bright | 4 | $11.41 | Available to order | 4 |
| 8 | T2107009 Kit, Water Elbow, Cast | Kit, Water Elbow, Cast | 1 | $57.03 | Available to order | 1 |
| 9 | T2102242 Hose Clip, 23-35, Bright, Ss | Hose Clip, 23-35, Bright, Ss | 5 | $7.73 | Available to order | 5 |
| 10 | T3600190 O Ring, 24 x 2.5 | O Ring, 24 x 2.5 | 2 | $1.13 | Available to order | 2 |
| 11 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 2 | $4.55 | Available to order | 2 |
| 12 | T2108016 Elbow | Elbow | 1 | $16.08 | Obsolete | View Details |
| 13 | T3202030 Bolt, RHHF, Domed, M6 x 20 | Bolt, RHHF, Domed, M6 x 20 M6 x 28mm | 2 | $1.22 | Obsolete | View Details |
| 14 | T2108031 Hose | Hose Head to Radiator ** Part No Longer Available ** | 1 | $50.80 | Obsolete | View Details |
| 15 | T2102115 Clip, 40-60, Bright | Clip, 40-60, Bright | 1 | $4.74 | Available to order | 1 |
| 16 | 2102130-T0301 Thermostat | Thermostat | 1 | $32.52 | Unavailable | View Details |
| 17 | T2108023 Hose | Hose Radiator to Pump | 1 | $47.42 | Available to order | 1 |
| 18 | T2108024 Hose | Hose * PART NO LONGER AVAILABLE * Oil Cooler to Radiator | 1 | $34.73 | Obsolete | View Details |
| 19 | T2108002 Radiator | Radiator | 1 | $658.75 | Obsolete | View Details |
| 20 | T2101360 Expansion tank | Expansion tank | 1 | $66.26 | Obsolete | View Details |
| 21 | T2108050 Fan assembly | Fan assembly | 1 | $551.67 | Obsolete | View Details |
| 22 | T3331517 Screw, P/HD Tx, Shld, M6 x 16, S | Screw, P/HD Tx, Shld, M6 x 16, S | 3 | $0.97 | Available to order | 3 |
| 24 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 2 | $1.40 | Available to order | 2 |
| 25 | T3555004 Washer, 6.4 x 14 x 1.6 | Washer, 6.4 x 14 x 1.6 | 2 | $1.40 | Available to order | 2 |
| 27 | T3010702 Flanged Sleeve, 6.4 x 10 x 8.5 | Flanged Sleeve, 6.4 x 10 x 8.5 | 4 | $5.78 | Available to order | 4 |
| 28 | T3020153 Grommet, 13 x 3 x 10 | Grommet, 13 x 3 x 10 | 4 | $1.91 | Available to order | 4 |
| 29 | T3620300 Overflow pipe | Overflow pipe | 1 | $13.18 | Available to order | 1 |
| 30 | T2100997 Cap, Expansion Tank | Cap, Expansion Tank | 1 | $9.52 | Available to order | 1 |
| 31 | T2101361 Hose | Hose | 1 | $17.43 | Obsolete | View Details |
| 32 | T3700440 Clip, Hose, 11-12.5mm | Clip, Hose, 11-12.5mm | 2 | $5.42 | Available to order | 2 |
| 33 | T2100808 Sensor, Engine Coolant | Sensor, Engine Coolant Engine coolant | 1 | $54.02 | Available to order | 1 |
| 34 | T3550571 Washer, Cu, OD 16 x ID 12.5 | Washer, Cu, OD 16 x ID 12.5 | 1 | $5.07 | Available to order | 1 |
| 36 | T2108101 Restrictor | Restrictor | 1 | $34.25 | Obsolete | View Details |
| 37 | T2108005 Cap, Radiator | Cap, Radiator | 1 | $19.97 | Available to order | 1 |
| 38 | T2108006 Bleed screw | Bleed screw | 1 | $2.16 | Obsolete | View Details |
| 39 | T4007777 Coolant, OAT, Premix, D2053,12 x 1L | Coolant, OAT, Premix, D2053,12 x 1L Not Illustrated | — | $187.12 | Available to order | 1 |
