Engine Management System
Parts (9)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1290485 Electronic Control Module | Electronic Control Module | 1 | $2075.70 | Obsolete | View Details |
| 2 | T3331234 Screw, Torx, P/H, M6 x 20, Slv | Screw, Torx, P/H, M6 x 20, Slv | 2 | $5.65 | Available to order | 2 |
| 3 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 M6 | 2 | $0.71 | Available to order | 2 |
| 4 | T1290038 Sensor | Sensor Crankshaft position | 1 | $186.74 | Available to order | 1 |
| 5 | T1290239 O Ring, Crankshaft Sensor | O Ring, Crankshaft Sensor | 1 | $5.65 | Backorder — Mid October 2026 | 1 |
| 6 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 1 | $1.50 | Available to order | 1 |
| 7 | T1290037 Ignition Coil, Plug Top, 4-Cyl | Ignition Coil, Plug Top, 4-Cyl | 4 | $164.77 | Available to order | 4 |
| 8 | T1290023 Spark plug | Spark plug | 4 | $18.14 | Available to order | 4 |
| 9 | T1297000 Sensor, Air Temperature | Sensor, Air Temperature Air temperature | 1 | $56.42 | Available to order | 1 |
