Rear Wheel/Final Drive
Parts (29)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2010345 Wheel assembly | Wheel assembly 5.5 X 17 Silver | 1 | $687.40 | Obsolete | View Details |
| 2 | T2004204 Spacer, Wheel | Spacer, Wheel | 1 | $48.49 | Available to order | 1 |
| 3 | T3800703 Bearing, Ball, 20 47 14 | Bearing, Ball, 20 47 14 | 2 | $45.80 | Available to order | 2 |
| 4 | T3500402 Circlip, Int Dia 47 | Circlip, Int Dia 47 | 1 | $0.95 | Available to order | 1 |
| 5 | T3600701 Oil Seal, DC 28 47 7 | Oil Seal, DC 28 47 7 | 1 | $23.35 | Available to order | 1 |
| 6 | T2012030 Spindle | Spindle * Part No Longer Available * | 1 | $45.40 | Obsolete | View Details |
| 7 | T2012032 Spacer | Spacer * Part No Longer Available * | 1 | $11.44 | Obsolete | View Details |
| 8 | T2012033 Stepped spacer | Stepped spacer | 1 | $29.95 | Available to order | 1 |
| 9 | T2012223 Rubber Cush Drive | Rubber Cush Drive | 1 | $109.86 | Available to order | 1 |
| 10 | T2012140 Sprocket carrier assembly | Sprocket carrier assembly | 1 | $698.06 | Available to order | 1 |
| 11 | T2012113 Ring | Ring | 1 | $43.14 | Available to order | 1 |
| 12 | T3800029 Bearing Ball, 25 52 15 | Bearing Ball, 25 52 15 | 1 | $16.91 | Available to order | 1 |
| 13 | T3500203 Circlip, Int, 52 x 2 | Circlip, Int, 52 x 2 | 1 | $16.64 | Available to order | 1 |
| 14 | T3600073 Oil Seal, 35 52 6 | Oil Seal, 35 52 6 | 1 | $22.67 | Available to order | 1 |
| 15 | T2012144 Stud, Sprocket Carrier | Stud, Sprocket Carrier | 5 | $8.11 | Available to order | 5 |
| 16 | T2010647 Spacer Tube, 35 x 20 x 12.5 | Spacer Tube, 35 x 20 x 12.5 | 1 | $8.61 | Available to order | 1 |
| 17 | T2059052 Block, Chain Adj, LH | Block, Chain Adj, LH | 1 | $43.64 | Available to order | 1 |
| 18 | T3555035 Washer, 19 x 34 x 3 | Washer, 19 x 34 x 3 | 1 | $1.36 | Backorder — Early October 2026 | 1 |
| 19 | T3350118 Locknut, Plain, M18 | Locknut, Plain, M18 | 1 | $12.00 | Available to order | 1 |
| 20 | T3350250 Locknut, Flanged, M10 | Locknut, Flanged, M10 | 5 | $4.43 | Available to order | 5 |
| 21 | T2059051 Block, Chain Adj, RH | Block, Chain Adj, RH | 1 | $43.64 | Available to order | 1 |
| 22 | T2012513 Sprocket | Sprocket » 152322 42T | 1 | $50.41 | Available to order | 1 |
| 22 | T2012517 Sprocket | Sprocket 42T 152323 » 165716 (Engine No. 166383) | 1 | $45.58 | Obsolete | View Details |
| 22 | T2012546 Sprocket | Sprocket 45T 165717 (Engine No.166384) » | 1 | $53.84 | Available to order | 1 |
| 23 | T2012525 Chain | Chain 106L » 165716 (Engine No.166383) | 1 | $241.11 | Available to order | 1 |
| 23 | T2013108 Chain | Chain 108L 165717 (Engine No.166384) » | 1 | $239.65 | Obsolete | View Details |
| 23 | T2017505 525 Chain,108L, Split, Spares | 525 Chain,108L, Split, Spares | 1 | $176.39 | Available to order | 1 |
| 24 | T2017184 Chain & Sprocket Kit, 106/42/14 | Chain & Sprocket Kit, 106/42/14 > 152322 | 1 | $261.86 | Available to order | 1 |
| 24 | T2017500 Chain & Sprocket Kit, 108/45/15 | Chain & Sprocket Kit, 108/45/15 152323> | 1 | $261.86 | Available to order | 1 |
