Rear Swinging Arm
Parts (21)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2050827 Chain Guide, Moulded, Black | Chain Guide, Moulded, Black | 1 | $1.73 | Available to order | 1 |
| 2 | T2051026 Chain Guard, XSM, Mldg, BLk | Chain Guard, XSM, Mldg, BLk | 1 | $5.12 | Available to order | 1 |
| 3 | T2051442 Swingarm, TXP-12, Pntd, Blk | Swingarm, TXP-12, Pntd, Blk | 1 | $117.54 | Available to order | 1 |
| 4 | T2051521 Side Stand Rob, Steel, Blk | Side Stand Rob, Steel, Blk | 1 | $9.23 | Available to order | 1 |
| 5 | T2050825 Swingarm Axle, Assy, Blk | Swingarm Axle, Assy, Blk | 1 | $23.74 | Available to order | 1 |
| 6 | T2053605 Compression Spring, SS | Compression Spring, SS | 1 | $0.99 | Available to order | 1 |
| 7 | T2053616 Snail Cam Top Hat Sleeve, Alu | Snail Cam Top Hat Sleeve, Alu | 2 | $4.00 | Available to order | 2 |
| 8 | T2053617 Snail Cam, Alu | Snail Cam, Alu | 2 | $0.06 | Available to order | 2 |
| 9 | T2053626 Caliper Sliding Mount 160 ISO | Caliper Sliding Mount 160 ISO | 1 | $16.95 | Out of Stock | Notify Me |
| 10 | T2053620 Side Stand Boot, Blk | Side Stand Boot, Blk | 1 | $0.63 | Available to order | 1 |
| 11 | T2053621 Side Stand Sleeve, SS | Side Stand Sleeve, SS | 1 | $2.61 | Available to order | 1 |
| 12 | T2053622 Side Stand Spring Top Hat, Blk | Side Stand Spring Top Hat, Blk | 1 | — | Unavailable | View Details |
| 13 | T2055175 Decal, Tri TXP-12, SARM, Lhs | Decal, Tri TXP-12, SARM, Lhs | 1 | $9.34 | Available to order | 1 |
| 14 | T2055176 Decal, Tri TXP-12 SARM, Rhs | Decal, Tri TXP-12 SARM, Rhs | 1 | $9.34 | Available to order | 1 |
| 15 | T3331061 Bolt, But/Hd, M5 x 11, Shld, Slv | Bolt, But/Hd, M5 x 11, Shld, Slv | 1 | $5.35 | Available to order | 1 |
| 16 | TOS30007 Bolt, M4X8Mm, Csk, SS A2 | Bolt, M4X8Mm, Csk, SS A2 | 1 | $0.53 | Available to order | 1 |
| 17 | TOS30021 Bolt, M5X10Mm, Flgd, 10.9, Blk | Bolt, M5X10Mm, Flgd, 10.9, Blk | 1 | $1.61 | Available to order | 1 |
| 18 | TOS30064 Circlip, Internal, 14Mm | Circlip, Internal, 14Mm | 2 | $0.35 | Available to order | 2 |
| 19 | TOS30079 Bolt, M6X25Mm, Flgd Butt, A2 | Bolt, M6X25Mm, Flgd Butt, A2 | 1 | $0.40 | Available to order | 1 |
| 20 | T3350305 Locknut, Flgd, M6 x 1.0, Slv | Locknut, Flgd, M6 x 1.0, Slv | 1 | $2.04 | Available to order | 1 |
| 21 | TOS30081 Bolt, M8X35Mm, Cap, 10.9, Blk | Bolt, M8X35Mm, Cap, 10.9, Blk | 2 | $0.99 | Available to order | 2 |
