Rear Wheel
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2003018 Rim Tape, 16"X25Mm | Rim Tape, 16"X25Mm | 1 | $5.03 | Available to order | 1 |
| 2 | T2011394 Tube, 16X2.5-3.0" BC | Tube, 16X2.5-3.0" BC | 1 | $8.76 | Available to order | 1 |
| 3 | T2011396 Chain, #219, 12Mm, 134 Links | Chain, #219, 12Mm, 134 Links | 1 | $38.02 | Backorder — Mid October 2026 | 1 |
| 4 | T2014076 Masterlink, #219, 12Mm, Gold | Masterlink, #219, 12Mm, Gold | 1 | $14.00 | Available to order | 1 |
| 5 | T2011433 Rr Sprocket, 76T, Steel, Blk | Rr Sprocket, 76T, Steel, Blk | 1 | $27.25 | Available to order | 1 |
| 6 | T2011476 Tyre, R, Trials, BC, 16X2.80" | Tyre, R, Trials, BC, 16X2.80" | 1 | $34.03 | Backorder — Early December 2026 | 1 |
| 7 | T2013400 Rear Wheel, 16" BC, Black | Rear Wheel, 16" BC, Black | 1 | $130.26 | Backorder — Mid October 2026 | 1 |
| 8 | T2003274 Nipple, 14GX14Mm, Chrome | Nipple, 14GX14Mm, Chrome | 28 | $0.62 | Out of Stock | Notify Me |
| 9 | T2003295 Rim, 16X1.25" BC, 28H, Alu, Blk | Rim, 16X1.25" BC, 28H, Alu, Blk | 1 | $123.94 | Out of Stock | Notify Me |
| 10 | T2011458 Hub, Rr, 12X125, 28H, Alu, Blk | Hub, Rr, 12X125, 28H, Alu, Blk | 1 | $86.13 | Out of Stock | Notify Me |
| 11 | T2011431 Axle, Rr, Bolt on, Steel, Blk | Axle, Rr, Bolt on, Steel, Blk | 1 | — | Unavailable | View Details |
| 13 | T2011465 Nut, Hub Bearing, Alu, Blk | Nut, Hub Bearing, Alu, Blk | 1 | $1.55 | Out of Stock | Notify Me |
| 14 | T2011466 Nut, Hub Bearing, Alu, Blk | Nut, Hub Bearing, Alu, Blk | 1 | $1.55 | Out of Stock | Notify Me |
| 15 | TOS30072 Bearing, RS, 10X26X8Mm | Bearing, RS, 10X26X8Mm | 2 | — | Unavailable | View Details |
| 16 | TOS30075 Nut, Axle, 3-8" 26TPI, Blk | Nut, Axle, 3-8" 26TPI, Blk | 2 | $1.55 | Out of Stock | Notify Me |
| 17 | T2022776 Brk Rotor, Solid, 160Mm | Brk Rotor, Solid, 160Mm | 1 | $28.47 | Out of Stock | Notify Me |
| 18 | T2022991 Bolt, M5X10Mm, Torx, Blk | Bolt, M5X10Mm, Torx, Blk | 6 | $1.15 | Out of Stock | Notify Me |
| 19 | TOS30005 Bolt,M6X16Mm,Cap+Wash,10.9,Blk | Bolt,M6X16Mm,Cap+Wash,10.9,Blk | 6 | $1.24 | Available to order | 6 |
| 20 | T2003230 Spoke, 14G, 125MM, Blk | Spoke, 14G, 125MM, Blk | 14 | $1.86 | Out of Stock | Notify Me |
| 20 | T2003235 Spoke, 14G, 128MM, Blk | Spoke, 14G, 128MM, Blk | 14 | $1.86 | Out of Stock | Notify Me |
