Front Mudguard
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2314403 Fr Mudguard, Mldg, Med, Blk | Fr Mudguard, Mldg, Med, Blk | 1 | $21.73 | Out of Stock | Notify Me |
| 2 | T2312963 Brkt, Fr Mudguard, Txp-20, Blk | Brkt, Fr Mudguard, Txp-20, Blk | 1 | $4.60 | Available to order | 1 |
| 3 | TOS30044 Bolt, M5X12Mm, Butt, 10.9, Blk | Bolt, M5X12Mm, Butt, 10.9, Blk | 2 | $1.15 | Available to order | 2 |
| 4 | TOS30018 Washer, M5, Form A, Steel, Blk | Washer, M5, Form A, Steel, Blk | 4 | $0.53 | Available to order | 4 |
| 5 | TOS30019 Nut, M5, Domed, SS A2 | Nut, M5, Domed, SS A2 | 2 | $1.29 | Available to order | 2 |
| 6 | TOS30021 Bolt, M5X10Mm, Flgd, 10.9, Blk | Bolt, M5X10Mm, Flgd, 10.9, Blk | 2 | $1.61 | Available to order | 2 |
| 7 | T2314331 Decal, Tri TXP-20, Trials, Mguard | Decal, Tri TXP-20, Trials, Mguard | 1 | $9.34 | Out of Stock | Notify Me |
| 8 | T2314341 Decal, Tri TXP, Numberboard, Med | Decal, Tri TXP, Numberboard, Med | 1 | $9.34 | Out of Stock | Notify Me |
| 9 | T2314244 Decal, Tri TXP, Fr Mudguard, Med | Decal, Tri TXP, Fr Mudguard, Med | 1 | $9.34 | Out of Stock | Notify Me |
| 10 | T2312961 Mudguard Front, Mould, 435Mm | Mudguard Front, Mould, 435Mm | 1 | $20.90 | Available to order | 1 |
| 11 | T3331436 Screw, S/Tap, Pan, Torx, 4 x 11, PT | Screw, S/Tap, Pan, Torx, 4 x 11, PT | 4 | $0.81 | Available to order | 4 |
| 12 | T2314395 Fr Mudguard, Brkt, Med, Blk | Fr Mudguard, Brkt, Med, Blk | 1 | $18.20 | Out of Stock | Notify Me |
| 13 | TOS30057 Star Nut, M6, 1'', Stl | Star Nut, M6, 1'', Stl | 1 | $6.74 | Available to order | 1 |
| 14 | TOS30079 Bolt, M6X25Mm, Flgd Butt, A2 | Bolt, M6X25Mm, Flgd Butt, A2 | 1 | $0.40 | Available to order | 1 |
