Rear Wheel
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2012029 Axle, Rear, 12X210Mm, Alu, Blk | Axle, Rear, 12X210Mm, Alu, Blk | 1 | $27.00 | Available to order | 1 |
| 2 | TOS30014 Washer Cup, Rr Axle, M12, Blk | Washer Cup, Rr Axle, M12, Blk | 2 | $6.59 | Available to order | 2 |
| 3 | TOS30015 Nut,Axle,M12X1.50,Flgd,Alu,Blk | Nut,Axle,M12X1.50,Flgd,Alu,Blk | 2 | $8.74 | Available to order | 2 |
| 4 | T2014206 Rear Sprocket,102T, Alu, Black | Rear Sprocket,102T, Alu, Black | 1 | $54.94 | Available to order | 1 |
| 5 | TOS30005 Bolt,M6X16Mm,Cap+Wash,10.9,Blk | Bolt,M6X16Mm,Cap+Wash,10.9,Blk | 6 | $1.24 | Available to order | 6 |
| 6 | T2014321 Rear Wheel, 17'' Mc, Black | Rear Wheel, 17'' Mc, Black | 1 | $265.25 | Out of Stock | Notify Me |
| 7 | T2011243 Hub, Rear, 12X152Mm, Alu, Blk | Hub, Rear, 12X152Mm, Alu, Blk | 1 | $110.50 | Out of Stock | Notify Me |
| 8 | T2014318 Rim, 17X1.85'' Mc, 36H, Black | Rim, 17X1.85'' Mc, 36H, Black | 1 | $143.00 | Out of Stock | Notify Me |
| 9 | T2011308 Spoke, 12G X 185Mm, Black | Spoke, 12G X 185Mm, Black | 36 | $2.15 | Available to order | 36 |
| 10 | T2009933 Nipple, 12G X 13Mm, Chrome | Nipple, 12G X 13Mm, Chrome | 36 | $1.07 | Available to order | 36 |
| 11 | T2014317 Rim Tape, 17''X50Mm, Mc | Rim Tape, 17''X50Mm, Mc | 1 | $6.24 | Out of Stock | Notify Me |
| 12 | T2014313 Rim Lock, 1.85'' Rims | Rim Lock, 1.85'' Rims | 1 | $0.75 | Available to order | 1 |
| 13 | T2014312 Tube, 17X3.50'' Mc | Tube, 17X3.50'' Mc | 1 | $22.40 | Available to order | 1 |
| 14 | T2014311 Tyre R, Max Gripper, 17X3.50'' | Tyre R, Max Gripper, 17X3.50'' | 1 | $92.22 | Available to order | 1 |
| 15 | T2022745 Brk Rotor, Solid, 180Mm | Brk Rotor, Solid, 180Mm | 1 | $21.84 | Available to order | 1 |
| 16 | TOS30013 Bolt, M5X10Mm, Torx, 10.9, Blk | Bolt, M5X10Mm, Torx, 10.9, Blk | 6 | $1.15 | Available to order | 6 |
| 17 | T2014077 Chain, #219, 12Mm, 170 Links, Gold | Chain, #219, 12Mm, 170 Links, Gold | 1 | $43.97 | Available to order | 1 |
| 18 | T2014076 Masterlink, #219, 12Mm, Gold | Masterlink, #219, 12Mm, Gold | 1 | $14.00 | Available to order | 1 |
| 19 | T2011294 Hub Spacer, Rear, Alu, Blk | Hub Spacer, Rear, Alu, Blk | 2 | $14.56 | Available to order | 2 |
| 20 | T2011291 Axle, Rr, Bearing, 12 X 151Mm, Alu, Blk | Axle, Rr, Bearing, 12 X 151Mm, Alu, Blk | 1 | $60.06 | Available to order | 1 |
| 22 | T2011257 Bearing RS, 15X28X7Mm | Bearing RS, 15X28X7Mm | 1 | $10.49 | Available to order | 1 |
| 23 | T2011288 Axial Seal, 22X28X4Mm, HM1 R | Axial Seal, 22X28X4Mm, HM1 R | 2 | $21.00 | Available to order | 2 |
| 24 | T2012057 Hub Shell, Rr, 152Mm, Alu, Blk | Hub Shell, Rr, 152Mm, Alu, Blk | 1 | — | Unavailable | View Details |
| 25 | TOS30025 O-Ring, 15X1.5Mm | O-Ring, 15X1.5Mm | 2 | $0.09 | Available to order | 2 |
| 26 | T2011510 Bearing, RS, 15X28X7Mm | Bearing, RS, 15X28X7Mm | 2 | $10.49 | Available to order | 2 |
| 27 | T2011382 Rr Wheel & Rim Tape, 17X1.85" | Rr Wheel & Rim Tape, 17X1.85" | 1 | $266.44 | Available to order | 1 |
| 28 | T2011497 Decal, Tri TXP-24, Rr Sprocket | Decal, Tri TXP-24, Rr Sprocket | 1 | $12.12 | Out of Stock | Notify Me |
