Instruments
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2505081 Instrument Assy, MPH | Instrument Assy, MPH UK,SG,US,TW,CA & CY | 1 | $508.36 | Obsolete | View Details |
| 1 | T2505082 Instrument Assy, KPH | Instrument Assy, KPH All Mkts Expt UK,SG,US,TW,CA & CY | 1 | $568.40 | Obsolete | View Details |
| 2 | T2505083 Speedometer Assy, MPH | Speedometer Assy, MPH UK,SG,US,TW,CA & CY - F2 | 1 | $316.39 | Obsolete | View Details |
| 2 | T2505084 Speedometer Assy, KPH | Speedometer Assy, KPH All Mkts Expt UK,SG,US,TW,CA & CY | 1 | $355.47 | Obsolete | View Details |
| 3 | T2505064 Mounting rubber | Mounting rubber | 2 | $6.27 | Available to order | 2 |
| 4 | T2505058 Bracket, Speedometer | Bracket, Speedometer | 1 | $55.98 | Available to order | 1 |
| 5 | T2505061 Canister, Speedometer | Canister, Speedometer | 1 | $115.33 | Available to order | 1 |
| 6 | T3350061 Nut, M5 | Nut, M5 | 2 | $1.84 | Available to order | 2 |
| 7 | T3350057 Washer, M5 | Washer, M5 | 2 | $1.84 | Available to order | 2 |
| 8 | T3332130 Bolt, H/HD, M4 x 16, Slv | Bolt, H/HD, M4 x 16, Slv | 1 | $0.61 | Available to order | 1 |
| 9 | T3050230 Screw, M4 x 14/Spring Washer | Screw, M4 x 14/Spring Washer | 2 | $2.24 | Backorder — Mid October 2026 | 2 |
| 10 | T2505062 Drive 90, Angled Speedometer | Drive 90, Angled Speedometer | 1 | $54.40 | Obsolete | View Details |
| 11 | T2501169 KNOB,TRIP, SPEEDOMETER | KNOB,TRIP, SPEEDOMETER | 1 | $6.67 | Obsolete | View Details |
| 12 | T2505063 Harness, Speedometer | Harness, Speedometer | 1 | $98.89 | Backorder — Mid October 2026 | 1 |
| 13 | T2502089 Bulb, T10 12v 1.7w | Bulb, T10 12v 1.7w 12V, 1.7W, 10mm Dia | 1 | $2.91 | Available to order | 1 |
| 14 | T2502090 Bulb, T6.5 12v 1.7w | Bulb, T6.5 12v 1.7w 12V, 1.7W, 6.5mm Dia | 1 | $5.97 | Unavailable | View Details |
| 15 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 2 | $3.73 | Available to order | 2 |
| 16 | T2501205 Screw, Reset Knob | Screw, Reset Knob | 1 | $1.50 | Available to order | 1 |
| 17 | T2505065 Gasket, Speedo Canister | Gasket, Speedo Canister * PART NO LONGER AVAILABLE * | 1 | $14.35 | Obsolete | View Details |
