Transmission
Parts (31)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1180042 Shaft, Input & 1st Gear | Shaft, Input & 1st Gear | 1 | $288.70 | Available to order | 1 |
| 2 | T1180048 Shaft, Output | Shaft, Output | 1 | $250.98 | Available to order | 1 |
| 3 | T1180031 Gear, 2nd, Input | Gear, 2nd, Input | 1 | $69.37 | Available to order | 1 |
| 4 | T1180032 Gear, 3rd & 4th, Input | Gear, 3rd & 4th, Input | 1 | $174.91 | Available to order | 1 |
| 5 | T1180033 Gear, Top, Input | Gear, Top, Input | 1 | $133.08 | Available to order | 1 |
| 6 | T1180034 Bush, Splined, Top, Input | Bush, Splined, Top, Input | 1 | $70.35 | Available to order | 1 |
| 7 | T1180045 Gear Assy, 1st Output | Gear Assy, 1st Output | 1 | $152.11 | Available to order | 1 |
| 8 | T1180047 Gear Assy, 2nd, Output | Gear Assy, 2nd, Output | 1 | $148.31 | Available to order | 1 |
| 9 | T1180037 Gear, 3rd, Output | Gear, 3rd, Output | 1 | $103.55 | Obsolete | View Details |
| 10 | T1180038 Bush, Splined, 3rd/4th, Output | Bush, Splined, 3rd/4th, Output | 1 | $50.37 | Available to order | 1 |
| 11 | T1180039 Gear, 4th, Output | Gear, 4th, Output | 1 | $102.64 | Available to order | 1 |
| 12 | T1180043 Spacer, Dogged, Output | Spacer, Dogged, Output | 1 | $78.87 | Available to order | 1 |
| 13 | T1180041 Gear, Top, Output | Gear, Top, Output | 1 | $138.75 | Available to order | 1 |
| 14 | T3800006 Bearing, Needle, K25x32x16 | Bearing, Needle, K25x32x16 | 2 | $17.21 | Available to order | 2 |
| 15 | T1180156 Sleeve Assy, Needle bearing | Sleeve Assy, Needle bearing | 2 | $63.70 | Available to order | 2 |
| 16 | 3800002-T0301 Bearing, Ball, DG2868 GN1C3 | Bearing, Ball, DG2868 GN1C3 | 1 | $43.51 | Available to order | 1 |
| 17 | T3800196 Retaining Ring, Bearing | Retaining Ring, Bearing | 1 | $4.92 | Available to order | 1 |
| 18 | T3800132 Bearing, 30 x 62 x 16, DGB | Bearing, 30 x 62 x 16, DGB | 1 | $119.76 | Out of Stock | Notify Me |
| 19 | T3800300 Snap Ring, Ext, 62 x 1.7 | Snap Ring, Ext, 62 x 1.7 | 1 | $3.59 | Available to order | 1 |
| 20 | T1181188 Distance Sleeve | Distance Sleeve | 1 | $4.12 | Available to order | 1 |
| 21 | T1180175 Nut, Gearbox Sprocket | Nut, Gearbox Sprocket | 1 | $5.56 | Available to order | 1 |
| 22 | T1180181 Washer, Gearbox Sprocket | Washer, Gearbox Sprocket | 1 | $7.56 | Available to order | 1 |
| 23 | T1182000 Sprocket, Gearbox (18T) | Sprocket, Gearbox (18T) > Eng No 695802 | 1 | $36.78 | Available to order | 1 |
| 23 | T1182003 Sprocket, Gearbox (18T) | Sprocket, Gearbox (18T) Eng No 695803 > | 1 | $36.78 | Out of Stock | Notify Me |
| 24 | T3600068 Seal, Oil, 40 62 6, Clockwise | Seal, Oil, 40 62 6, Clockwise | 1 | $11.79 | Available to order | 1 |
| 25 | T1180281 Washer, Thrust, Input | Washer, Thrust, Input | 2 | $3.70 | Available to order | 2 |
| 26 | T1180049 Washer, Thrust, 41 OD x 1 | Washer, Thrust, 41 OD x 1 | 3 | $3.70 | Available to order | 3 |
| 27 | T3500003 Circlip, 32mm Shaft | Circlip, 32mm Shaft | 2 | $7.02 | Available to order | 2 |
| 28 | T3500202 Circlip | Circlip | 3 | $5.60 | Available to order | 3 |
| 29 | T3555005 Washer, 25.5 x 38 x 1.5 | Washer, 25.5 x 38 x 1.5 | 2 | $3.70 | Available to order | 2 |
| 30 | T3500201 Circlip, EXT, 23.5 x 1.2 | Circlip, EXT, 23.5 x 1.2 | 2 | $4.36 | Available to order | 2 |
