Passenger Backrest Std + Luggage Rack Kit
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9738044 Passenger Backrest Std & Luggage Rack Kit | Passenger Backrest Std & Luggage Rack Kit Logo badge not inlcuded - Includes back rest pad | 1 | $123.00 | Obsolete | View Details |
| 2 | A9750705 Passenger Backrest Standard | Passenger Backrest Standard | 1 | $142.00 | Obsolete | View Details |
| 3 | A9733466 Mounting Plate LH | Mounting Plate LH | 1 | $43.20 | Obsolete | View Details |
| 4 | A9733467 Mounting Plate RH | Mounting Plate RH PART NO LONGER AVAILABLE | 1 | $43.50 | Obsolete | View Details |
| 5 | T3205067 Bolt, HHF, Lghtd, M6 x 25, Slv | Bolt, HHF, Lghtd, M6 x 25, Slv | 4 | $2.46 | Available to order | 4 |
| 6 | A9910141 Screw, M8 x 40, Caphead, S/S | Screw, M8 x 40, Caphead, S/S | 2 | $1.10 | Obsolete | View Details |
| 7 | A9910142 Screw, M8 x 45, Caphead, S/S | Screw, M8 x 45, Caphead, S/S | 2 | $1.60 | Obsolete | View Details |
| 8 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 | 4 | $0.67 | Available to order | 4 |
| 9 | T3450124 Cap | Cap | 4 | $5.60 | Available to order | 4 |
| 10 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 4 | $4.19 | Backorder — Mid August 2026 | 4 |
| 11 | T2700443 Reflector, Oval, Red | Reflector, Oval, Red | 2 | $6.14 | Available to order | 2 |
| 12 | T2300348 Passenger Backrest Pad | Passenger Backrest Pad | 1 | $27.00 | Obsolete | View Details |
| 13 | A9910052 Screw, Domehead, M6 x 12 | Screw, Domehead, M6 x 12 | 4 | $2.70 | Available to order | 4 |
| 14 | A9930007 Cleaning Swab | Cleaning Swab | 1 | $1.62 | Available to order | 1 |
| 15 | A9733473 Luggage rack | Luggage rack | 1 | $92.00 | Obsolete | View Details |
