Rear Mudguard, Short, Kit - US Only
Schematic
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9700401-PG Painted Short Rear Mudguard | Painted Short Rear Mudguard Market Restrictions Apply - Jet Black - US Market Only - Also requires A9838046, multifunction light kit & A9750730, Side Mounted Number Plate Kit | 1 | $320.00 | Available to order | 1 |
| 1 | A9700401-PS Painted Short Rear Mudguard | Painted Short Rear Mudguard * PART NO LONGER AVAILABLE * Market Restrictions Apply - Matt Jet Black - US Market Only - Also requires A9838046, multifunction light kit & A9750730, Side Mounted Number Plate Kit | 1 | $290.00 | Obsolete | View Details |
| 2 | T9700439-PG Mudguard, Rear, Acc, Painted | Mudguard, Rear, Acc, Painted Jet Black | 1 | $319.30 | Available to order | 1 |
| 2 | T9700439-PS Mudguard, Rear, Acc, Painted | Mudguard, Rear, Acc, Painted Matt Jet Black | 1 | $324.45 | Available to order | 1 |
| 3 | T9701401-PG Cover, Rear Light | Cover, Rear Light Jet Black | 1 | $319.30 | Available to order | 1 |
| 3 | T9701401-PS Cover, Rear Light | Cover, Rear Light Matt Jet Black | 1 | $278.10 | Backorder — Late August 2026 | 1 |
| 4 | T9701400 Trim, Rear Cover, Rubber | Trim, Rear Cover, Rubber | 1 | $17.80 | Available to order | 1 |
| 5 | T9830098 Harness, Multifcn Lamp, Type 2 | Harness, Multifcn Lamp, Type 2 | 1 | $53.40 | Available to order | 1 |
| 6 | T3350010 Locknut, Flgd, M5 | Locknut, Flgd, M5 | 1 | $2.25 | Available to order | 1 |
| 7 | T3331436 Screw, S/Tap, Pan, Torx, 4 x 11, PT | Screw, S/Tap, Pan, Torx, 4 x 11, PT | 2 | $0.75 | Available to order | 2 |
| 8 | T3050348 Screw, Cap/Hd, M6 x 12, Enc, Slv | Screw, Cap/Hd, M6 x 12, Enc, Slv | 2 | $5.14 | Available to order | 2 |
| 9 | T3331044 Screw, Pan/Hd, Tx, M6 x 16, Slv | Screw, Pan/Hd, Tx, M6 x 16, Slv | 2 | $0.97 | Available to order | 2 |
| 10 | T9701406 Stay, Mudguard, Short, Blk, Gloss | Stay, Mudguard, Short, Blk, Gloss | 1 | $110.13 | Out of Stock | Notify Me |
| 12 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 1 | $2.45 | Available to order | 1 |
