Mirror, Peep, Clear
Schematic
Parts (17)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9638137 Peep Mirror, Clr Anodised | Peep Mirror, Clr Anodised Market Restrictions Apply - Also requires either A9630654, A9630250, A9630251, A9630556 or A9630655 | 1 | $131.00 | Obsolete | View Details |
| 2 | T3050334 Screw, Cap/Hd, M6 x 20, Slv | Screw, Cap/Hd, M6 x 20, Slv | 1 | $1.51 | Available to order | 1 |
| 3 | T2060251 Friction Ring, 25.4 | Friction Ring, 25.4 | 1 | $36.96 | Available to order | 1 |
| 4 | T2060499 Friction Ring, 22.2 | Friction Ring, 22.2 | 1 | $36.96 | Available to order | 1 |
| 5 | T9638187 Stem, Mirror, Peep, Clear | Stem, Mirror, Peep, Clear | 1 | $37.50 | Obsolete | View Details |
| 6 | T9638185 Ball End, Mirror, Dia 10, M6 x 12 | Ball End, Mirror, Dia 10, M6 x 12 | 1 | $7.79 | Available to order | 1 |
| 7 | T9638183 Head, Mirror, Peep, Assy, Clear | Head, Mirror, Peep, Assy, Clear | 1 | $31.00 | Obsolete | View Details |
| 8 | T9638190 Ball End Cup, Mirror, 12.8 x 4.5 | Ball End Cup, Mirror, 12.8 x 4.5 | 1 | $1.11 | Available to order | 1 |
| 9 | T9638189 Disc Spring, 5.2 x 12 x 0.5 | Disc Spring, 5.2 x 12 x 0.5 | 1 | $1.11 | Available to order | 1 |
| 10 | T9638188 Screw, Grub, M14 x 1.0, Slv | Screw, Grub, M14 x 1.0, Slv | 1 | $11.12 | Available to order | 1 |
| 11 | T9638184 Sleeve, Ball End, M14 x 1.0 | Sleeve, Ball End, M14 x 1.0 | 1 | $5.56 | Available to order | 1 |
| 12 | T2022021 Brake Grease Special | Brake Grease Special | 1 | $5.02 | Out of Stock | Notify Me |
| 13 | T3330923 Screw, Csk, M6 x 20, Slv, Enc | Screw, Csk, M6 x 20, Slv, Enc | 1 | $2.37 | Available to order | 1 |
| 14 | A9740065 Plug, Plastic, Black 10 x 15 x 9 | Plug, Plastic, Black 10 x 15 x 9 | 1 | $1.62 | Available to order | 1 |
| 15 | A9910854 Screw, But HD, M10 x 12 | Screw, But HD, M10 x 12 | 1 | $5.94 | Available to order | 1 |
| 16 | T3450114 Button, Fir Tree, Dia 8-8.6 | Button, Fir Tree, Dia 8-8.6 | 2 | $3.33 | Available to order | 2 |
| 17 | T2045856 Plastic Plug, 22.2 | Plastic Plug, 22.2 | 1 | $2.25 | Available to order | 1 |
