Rear Suspension Unit
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2054347 Rear Suspension Unit | Rear Suspension Unit | 1 | $668.93 | Available to order | 1 |
| 2 | T2051171 Ground Sleeve, RSU, Black | Ground Sleeve, RSU, Black | 1 | $48.49 | Out of Stock | Notify Me |
| 3 | T3600142 Oil Seal 15 21 3 | Oil Seal 15 21 3 | 2 | $25.85 | Available to order | 2 |
| 5 | T3800177 Bearing, Needle Roller, 17 24 15 | Bearing, Needle Roller, 17 24 15 | 1 | $17.69 | Available to order | 1 |
| 7 | T2057354 Sleeve, Linkage, Dia 20.0 x 30.5 | Sleeve, Linkage, Dia 20.0 x 30.5 | 1 | $10.71 | Available to order | 1 |
| 8 | T3332630 Screw, TX, M12 x 75, Slv | Screw, TX, M12 x 75, Slv | 1 | $6.27 | Available to order | 1 |
| 9 | T3202697 Bolt, TX, M10 x 60 | Bolt, TX, M10 x 60 | 2 | $5.30 | Available to order | 2 |
| 10 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 | 1 | $6.07 | Available to order | 1 |
| 11 | T2051965 Linkage Plate, Forged | Linkage Plate, Forged | 2 | $159.69 | Available to order | 2 |
| 12 | T2051970 Linkage Rod, Extruded | Linkage Rod, Extruded | 1 | $89.35 | Out of Stock | Notify Me |
| 13 | T3332690 Bolt, TX, M10 x 70 | Bolt, TX, M10 x 70 | 2 | $5.30 | Available to order | 2 |
| 14 | T3350250 Locknut, Flanged, M10 | Locknut, Flanged, M10 | 4 | $4.16 | Available to order | 4 |
| 15 | T3555029 Washer, 10.5 x 23 x 2 | Washer, 10.5 x 23 x 2 | 2 | $2.74 | Available to order | 2 |
| 16 | T3600066 Oil Seal, 24 17 5 | Oil Seal, 24 17 5 | 2 | $8.53 | Available to order | 2 |
| 17 | T2053130 Sleeve, Ground, 17 10 30 | Sleeve, Ground, 17 10 30 | 1 | $18.85 | Available to order | 1 |
| 18 | T2056505 Bush, Rubber Mount, 10.2 x 27 x 30 | Bush, Rubber Mount, 10.2 x 27 x 30 | 1 | $19.47 | Backorder — Late August 2026 | 1 |
