Loading schematic...
Handlebars and Switches
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2040729 Handlebar kit | Handlebar kit » 47600 LH/RH | 1 | $255.79 | Obsolete | View Details |
| 1 | T2040727 Handlebar lh | Handlebar lh 47601 » » 49060 | 1 | $135.94 | Obsolete | View Details |
| 1 | T2040723 Handlebar lh | Handlebar lh 105632 » | 1 | $133.28 | Obsolete | View Details |
| 2 | T2040728 Handlebar rh | Handlebar rh 47601 » » 49060 | 1 | $127.67 | Obsolete | View Details |
| 2 | T2040724 Handlebar rh | Handlebar rh 105632 » | 1 | $133.28 | Obsolete | View Details |
| 3 | T2040740 Handlebar Grip, LH | Handlebar Grip, LH LH | 1 | $18.83 | Available to order | 1 |
| 4 | T2040750 Grip | Grip RH | 1 | $18.83 | Available to order | 1 |
| 5 | T2040094 Switch assembly | Switch assembly UK, CH, DE, NL, FR, ES, BR, IT, NZ, ZA GR, AR, HK, PT, SE, CY - All Vins AU, » 79414 SG, » 110550 | 1 | $91.26 | Obsolete | View Details |
| 5 | T2040112 Switch assembly | Switch assembly CA, MY, US, JP - All Vins AU, » 79413 SG, » 110499 LH | 1 | $183.38 | Obsolete | View Details |
| 6 | T2040096 Switch Assy, Rh | Switch Assy, Rh RH | 1 | $177.56 | Available to order | 1 |
| 7 | T2040231 Actuator assembly | Actuator assembly PART NO LONGER AVAILABLE | 1 | $57.67 | Obsolete | View Details |
| 8 | T2040730 Handlebar Weight | Handlebar Weight | 2 | $29.44 | Obsolete | View Details |
| 8 | T2040731 Tubular Handlebar | Tubular Handlebar | 1 | $151.94 | Available to order | 1 |
| 9 | T3205653 Bolt, HHF, Lghtd, M8 x 30, Slv | Bolt, HHF, Lghtd, M8 x 30, Slv M8 Lightened | 2 | $1.29 | Available to order | 2 |
| 10 | T2040455 Throttle cable | Throttle cable PART NO LONGER AVAILABLE | 1 | $45.71 | Obsolete | View Details |
| 11 | T3331810 Screw, M5 X 40 | Screw, M5 X 40 M5 x 40mm | 1 | $0.77 | Obsolete | View Details |
| 12 | T3331790 Screw, Pan/Hd, Ph, M5 x 30, Blk | Screw, Pan/Hd, Ph, M5 x 30, Blk M5 x 30mm | 1 | $0.95 | Available to order | 1 |
| 13 | T3331800 Screw, M5 X 22 | Screw, M5 X 22 M5 x 22mm | 2 | $1.29 | Available to order | 2 |
| 14 | T1240941 Clip | Clip | 1 | $15.97 | Available to order | 1 |
| 15 | T3200082 Bolt, RHHF, M6 x 40, Bright | Bolt, RHHF, M6 x 40, Bright 105632 » M6 x 40mm | 2 | $0.87 | Obsolete | View Details |
