Instruments
Parts (30)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2504000 Speedometer mph | Speedometer mph | 1 | $334.79 | Obsolete | View Details |
| 1 | T2504005 Speedometer kph | Speedometer kph | 1 | $366.99 | Obsolete | View Details |
| 2 | 2500085-T0301 Bulb | Bulb 12V, 1.7W, 6.5mm Dia Speedometer gauge | 1 | $5.97 | Available to order | 1 |
| 3 | 2500095-T0301 Bulb | Bulb 12V, 1.7W, 10mm Dia Speedo, Tacho & Temp gauges | 4 | $6.54 | Available to order | 4 |
| 4 | T2504001 Harness | Harness Speedometer | 1 | $25.75 | Available to order | 1 |
| 5 | T2505018 Screw | Screw | 1 | $0.95 | Available to order | 1 |
| 6 | T2504002 Knob | Knob ** Part No Longer Available ** | 1 | $4.01 | Obsolete | View Details |
| 7 | T2504105 Tachometer | Tachometer | 1 | $157.18 | Obsolete | View Details |
| 8 | T2504101 Harness tacho | Harness tacho | 1 | $109.12 | Obsolete | View Details |
| 9 | T2504200 Temperature gauge | Temperature gauge | 1 | $101.95 | Obsolete | View Details |
| 10 | T2504300 Warning light | Warning light | 1 | $39.23 | Obsolete | View Details |
| 11 | T2500090 Bulb | Bulb 12V, 3.0W, 6.5mm Dia Warning light | 6 | $6.54 | Available to order | 6 |
| 13 | T2500490 Cover | Cover » 89736 | 1 | $22.34 | Obsolete | View Details |
| 14 | T2505016 Seal | Seal | 1 | $1.18 | Available to order | 1 |
| 15 | T3330262 Screw | Screw M4 x 16mm | 5 | $0.46 | Obsolete | View Details |
| 16 | T3550187 Washer c/sunk | Washer c/sunk PART NO LONGER AVAILABLE - M4 | 2 | $7.51 | Obsolete | View Details |
| 17 | T2500472 Seal | Seal Speedometer | 1 | $6.29 | Obsolete | View Details |
| 18 | T2500473 Seal | Seal Tachometer | 1 | $3.54 | Available to order | 1 |
| 19 | T2500474 Seal | Seal Temperature gauge | 1 | $3.14 | Out of Stock | Notify Me |
| 20 | T2500471 Cover instruments | Cover instruments | 1 | $16.61 | Obsolete | View Details |
| 21 | T2500315 Housing instruments | Housing instruments | 1 | $35.91 | Obsolete | View Details |
| 22 | T3020012 Grommet | Grommet * PART NO LONGER AVAILABLE * | 2 | $3.52 | Obsolete | View Details |
| 23 | T3010009 Flanged sleeve | Flanged sleeve M5 | 2 | $0.93 | Obsolete | View Details |
| 24 | T3338989 Screw, But/Hd, M5 x 20, S/S | Screw, But/Hd, M5 x 20, S/S | 2 | $7.20 | Available to order | 2 |
| 25 | T2505015 Grommet | Grommet PART NO LONGER AVAILABLE | 6 | $1.82 | Obsolete | View Details |
| 26 | T2700493 Nut & Washer Assy, M5, Slv | Nut & Washer Assy, M5, Slv | 6 | $1.91 | Available to order | 6 |
| 27 | T2040467 Speedometer cable | Speedometer cable PART NO LONGER AVAILABLE | 1 | $49.69 | Obsolete | View Details |
| 28 | T3331017 Screw. Phil CSK. M5 x 20, Slv | Screw. Phil CSK. M5 x 20, Slv | 1 | $4.53 | Available to order | 1 |
| 29 | T3450126 Plug | Plug | 1 | $0.38 | Obsolete | View Details |
| 30 | T2504201 Harness | Harness Temperature gauge | 1 | $40.38 | Obsolete | View Details |
