Front Forks and Yokes
Parts (36)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2042602-T0301 Stanchion assembly | Stanchion assembly LH 4 Cyl | 1 | $907.35 | Obsolete | View Details |
| 1 | 2042402-T0301 Stanchion assembly | Stanchion assembly LH 3 Cyl | 1 | $864.14 | Obsolete | View Details |
| 2 | 2042601-T0301 Stanchion assembly | Stanchion assembly RH 4 Cyl | 1 | $907.35 | Obsolete | View Details |
| 2 | 2042401-T0301 Stanchion assembly | Stanchion assembly RH 3 Cyl | 1 | $864.14 | Obsolete | View Details |
| 3 | 2040088-T0301 Tube outer | Tube outer LH | 1 | $551.16 | Obsolete | View Details |
| 3 | 2040066-T0301 Tube outer | Tube outer RH | 1 | $551.16 | Obsolete | View Details |
| 4 | 2040076-T0301 Sliding bush | Sliding bush | 2 | $14.73 | Available to order | 2 |
| 5 | 2040077-T0301 Washer | Washer | 2 | $3.74 | Obsolete | View Details |
| 6 | 2040078-T0301 Oil seal | Oil seal | 2 | $20.99 | Available to order | 2 |
| 7 | 2040079-T0301 Ring snap | Ring snap | 2 | $6.83 | Available to order | 2 |
| 8 | 2040080-T0301 Dust seal | Dust seal | 2 | $20.08 | Available to order | 2 |
| 9 | T2040073 Oil lock | Oil lock | 2 | $6.15 | Obsolete | View Details |
| 10 | T2020472 Circlip, M'cyl, Rear | Circlip, M'cyl, Rear | 1 | $2.74 | Available to order | 1 |
| 11 | 2040070-T0301 Cylinder assembly | Cylinder assembly 4 Cyl | 2 | $109.28 | Obsolete | View Details |
| 11 | T2042725 Cylinder assembly | Cylinder assembly 3 Cyl | 2 | $445.53 | Obsolete | View Details |
| 12 | 2040172-T0301 Bearing | Bearing | 2 | $9.88 | Available to order | 2 |
| 13 | 2040069-T0301 Tube inner | Tube inner PART NO LONGER AVAILABLE | 2 | $281.38 | Obsolete | View Details |
| 14 | T2042705 Spring | Spring 4 Cyl | 2 | $50.78 | Obsolete | View Details |
| 14 | T2042710 Spring | Spring 3 Cyl | 2 | $91.37 | Obsolete | View Details |
| 15 | 2040082-T0301 Washer spring | Washer spring PART NO LONGER AVAILABLE | 2 | $1.12 | Obsolete | View Details |
| 16 | 2040071-T0301 Top cap | Top cap | 2 | $68.35 | Obsolete | View Details |
| 17 | 2040075-T0301 Capscrew | Capscrew PART NO LONGER AVAILABLE | 2 | $19.42 | Obsolete | View Details |
| 18 | 2040074-T0301 Sealing washer | Sealing washer | 2 | $1.13 | Available to order | 2 |
| 19 | 2040805-T0301 Yoke | Yoke 40mm Top 4 Cyl | 1 | $203.78 | Obsolete | View Details |
| 19 | 2040059-T0301 Yoke | Yoke 35mm Top 3 Cyl | 1 | $203.78 | Obsolete | View Details |
| 20 | 2040803-T0301 Yoke assembly | Yoke assembly 40mm Bottom 4 Cyl | 1 | $363.73 | Obsolete | View Details |
| 20 | 2040064-T0301 Yoke assembly | Yoke assembly 35mm Bottom 3 Cyl | 1 | $363.73 | Obsolete | View Details |
| 21 | T3051032 Screw, Cap/HD, M8 x 40, Slv | Screw, Cap/HD, M8 x 40, Slv | 10 | $1.51 | Available to order | 10 |
| 22 | 3450065-T0301 Cap | Cap | 3 | $0.57 | Obsolete | View Details |
| 23 | T2040061 Washer Upper Yoke | Washer Upper Yoke | 1 | $7.14 | Available to order | 1 |
| 24 | T2040060 Nut | Nut | 1 | $24.83 | Available to order | 1 |
| 25 | T2040081 O Ring, Fork Seal | O Ring, Fork Seal | 2 | $3.59 | Available to order | 2 |
| 26 | 2040173-T0301 Seal kit | Seal kit | 2 | $35.44 | Available to order | 2 |
| 27 | 3450010-T0301 Plug, Rubber, M8 | Plug, Rubber, M8 | 4 | $1.18 | Obsolete | View Details |
| 28 | 2040225-T0301 Adjuster nut | Adjuster nut PART NO LONGER AVAILABLE | 1 | $5.11 | Obsolete | View Details |
| 29 | T2140210 Adjuster Nut, Upper | Adjuster Nut, Upper | 1 | $3.39 | Available to order | 1 |
