Crankcase Fixings - Daytona 900 3 Cylinder » 9872
Parts (8)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T3330121 Screw, Torx | Screw, Torx PART NO LONGER AVAILABLE - Daytona 900 M8 x 105mm | 4 | $1.70 | Obsolete | View Details |
| 2 | 3330021-T0301 Screw, Torx | Screw, Torx M8 x 80mm | 4 | $5.60 | Available to order | 4 |
| 3 | 3330024-T0301 Screw, Torx | Screw, Torx M8 x 155mm - PART NO LONGER AVAILABLE | 2 | $6.46 | Obsolete | View Details |
| 4 | 3330043-T0301 Screw, Torx | Screw, Torx M8 x 130mm | 1 | $0.57 | Out of Stock | Notify Me |
| 5 | T3330040 Screw | Screw M8 x 65mm | 1 | $2.99 | Obsolete | View Details |
| 6 | 3330047-T0301 Screw, Torx | Screw, Torx M6 x 140mm | 3 | $0.90 | Obsolete | View Details |
| 7 | T3331299 Screw, Pan/HD, Tx, M6 x 40, Slv | Screw, Pan/HD, Tx, M6 x 40, Slv | 7 | $3.70 | Available to order | 7 |
| 8 | 3330031-T0301 Screw,torx | Screw,torx M6 x 130mm | 3 | $4.40 | Obsolete | View Details |
