Oil Cooler 4 Cylinder
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2101020-T0301 Oil cooler | Oil cooler » 35326 | 1 | $397.58 | Obsolete | View Details |
| 1 | T2101030 Oil cooler | Oil cooler 35327 » | 1 | $444.53 | Obsolete | View Details |
| 2 | 2101160-T0301 Grille | Grille | 1 | $8.68 | Obsolete | View Details |
| 3 | 2101001-T0301 Mounting plate | Mounting plate | 1 | $9.61 | Obsolete | View Details |
| 4 | T3350111 Nut, Captive, M6 | Nut, Captive, M6 | 4 | $4.92 | Backorder — Early August 2026 | 4 |
| 5 | T3331517 Screw, P/HD Tx, Shld, M6 x 16, S | Screw, P/HD Tx, Shld, M6 x 16, S Stoneguard mounting screws | 4 | $0.97 | Available to order | 4 |
| 6 | T3331234 Screw, Torx, P/H, M6 x 20, Slv | Screw, Torx, P/H, M6 x 20, Slv Oil cooler mounting screws | 1 | $5.30 | Available to order | 1 |
| 7 | T3010702 Flanged Sleeve, 6.4 x 10 x 8.5 | Flanged Sleeve, 6.4 x 10 x 8.5 | 3 | $5.78 | Available to order | 3 |
| 8 | T3021100 Grommet, Dia 13 x 1.8 | Grommet, Dia 13 x 1.8 | 3 | $2.85 | Available to order | 3 |
| 9 | 2100026-T0301 Oil return pipe | Oil return pipe » 35326 | 1 | $87.43 | Obsolete | View Details |
| 9 | T2100999 Oil return pipe | Oil return pipe 35327 » | 1 | $78.21 | Obsolete | View Details |
| 10 | 2100025-T0301 Oil feed pipe | Oil feed pipe » 35326 | 1 | $91.37 | Obsolete | View Details |
| 10 | T2100998 Oil feed pipe | Oil feed pipe 35327 » | 1 | $87.47 | Backorder — Late August 2026 | 1 |
| 11 | T3550547 Washer, Cu, OD19 x ID14.2 | Washer, Cu, OD19 x ID14.2 | 6 | $4.32 | Available to order | 6 |
| 12 | T1210241 Banjo Bolt, M14 x 28 | Banjo Bolt, M14 x 28 | 3 | $13.18 | Available to order | 3 |
| 13 | 2300057-T0301 Lower sub frame | Lower sub frame | 1 | $84.62 | Obsolete | View Details |
| 14 | 2300146-T0301 Bracket lh | Bracket lh | 1 | $9.61 | Obsolete | View Details |
| 14 | T2300579 Bracket lh | Bracket lh Special Edition Daytona 1200 | 1 | $13.07 | Obsolete | View Details |
| 15 | 2300051-T0301 Bracket rh | Bracket rh | 1 | $8.79 | Obsolete | View Details |
| 15 | T2300578 Bracket rh | Bracket rh Special Edition Daytona 1200 | 1 | $8.13 | Obsolete | View Details |
| 16 | 3210005-T0301 Bolt | Bolt M6 x 12mm | 4 | $0.80 | Obsolete | View Details |
| 17 | T3331625 Screw, Btn Hd, M8 x 12, Slv | Screw, Btn Hd, M8 x 12, Slv | 4 | $1.72 | Available to order | 4 |
