Front Forks and Yokes
Parts (49)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2042612-T0301 Stanchion assembly | Stanchion assembly » 9082 LH | 1 | $780.44 | Obsolete | View Details |
| 1 | T2042622 Stanchion assembly | Stanchion assembly 9083 » » 29155 LH | 1 | $831.06 | Obsolete | View Details |
| 1 | T2042675 Stanchion assembly | Stanchion assembly 29156 » » 33785 LH | 1 | $831.06 | Obsolete | View Details |
| 2 | 2042611-T0301 Stanchion assembly | Stanchion assembly » 9082 RH | 1 | $890.06 | Obsolete | View Details |
| 2 | T2042621 Stanchion assembly | Stanchion assembly 9083 » » 29155 RH | 1 | $890.06 | Obsolete | View Details |
| 2 | T2042676 Stanchion assembly | Stanchion assembly 29156 » » 33785 RH | 1 | $780.44 | Obsolete | View Details |
| 3 | 2040142-T0301 Tube outer | Tube outer LH | 1 | $220.59 | Obsolete | View Details |
| 3 | 2040141-T0301 Tube outer | Tube outer RH | 1 | $567.69 | Obsolete | View Details |
| 4 | 2040076-T0301 Sliding bush | Sliding bush | 2 | $15.28 | Available to order | 2 |
| 5 | 2040077-T0301 Washer | Washer | 2 | $4.30 | Obsolete | View Details |
| 6 | 2040078-T0301 Oil seal | Oil seal | 2 | $21.77 | Available to order | 2 |
| 7 | 2040079-T0301 Ring snap | Ring snap | 2 | $7.28 | Available to order | 2 |
| 8 | 2040080-T0301 Dust seal | Dust seal | 2 | $20.83 | Available to order | 2 |
| 9 | T2040073 Oil lock | Oil lock » 29155 | 2 | $6.54 | Obsolete | View Details |
| 9 | T2042020 Oil lock | Oil lock 29156 » » 33785 | 2 | $6.70 | Available to order | 2 |
| 10 | T2020472 Circlip, M'cyl, Rear | Circlip, M'cyl, Rear | 1 | $2.91 | Available to order | 1 |
| 11 | 2040070-T0301 Cylinder assembly | Cylinder assembly » 9082 | 2 | $113.65 | Obsolete | View Details |
| 11 | T2042735 Cylinder assembly | Cylinder assembly 9083 » » 29155 | 2 | $458.90 | Obsolete | View Details |
| 11 | T2042015 Cylinder assembly | Cylinder assembly 29156 » » 33785 | 2 | $458.90 | Obsolete | View Details |
| 12 | 2040172-T0301 Bearing | Bearing | 2 | $10.52 | Available to order | 2 |
| 13 | 2040069-T0301 Tube inner | Tube inner » 29155 - PART NO LONGER AVAILABLE | 2 | $289.82 | Obsolete | View Details |
| 13 | T2042010 Tube inner | Tube inner 29156 » » 33785 | 2 | $151.94 | Backorder — Mid November 2026 | 2 |
| 14 | T2042635 Spring | Spring » 9082 | 2 | $90.43 | Obsolete | View Details |
| 14 | T2042637 Spring | Spring 9083 » » 29155 | 2 | $86.62 | Obsolete | View Details |
| 14 | T2042025 Spring | Spring 29156 » » 33785 | 2 | $88.37 | Obsolete | View Details |
| 15 | 2040082-T0301 Washer spring | Washer spring PART NO LONGER AVAILABLE | 2 | $1.20 | Obsolete | View Details |
| 16 | 2040071-T0301 Top cap | Top cap | 2 | $72.45 | Obsolete | View Details |
| 17 | 2040075-T0301 Capscrew | Capscrew PART NO LONGER AVAILABLE | 2 | $21.75 | Obsolete | View Details |
| 18 | 2040074-T0301 Sealing washer | Sealing washer | 2 | $1.21 | Available to order | 2 |
| 19 | 2040902-T0301 Yoke | Yoke » 9082 40mm 4 Cyl | 1 | $211.59 | Obsolete | View Details |
| 19 | 2040912-T0301 Yoke | Yoke » 9082 35mm 3 Cyl | 1 | $211.93 | Obsolete | View Details |
| 19 | T2040907 Yoke | Yoke 9083 » 40mm 3 & 4 Cyl | 1 | $199.91 | Obsolete | View Details |
| 20 | T2040940 Yoke assembly | Yoke assembly » 9082 40mm 4 Cyl | 1 | $374.64 | Obsolete | View Details |
| 20 | T2040945 Yoke assembly | Yoke assembly » 9082 35mm 3 Cyl | 1 | $374.64 | Obsolete | View Details |
| 21 | T3051032 Screw, Cap/HD, M8 x 40, Slv | Screw, Cap/HD, M8 x 40, Slv | 10 | $1.61 | Available to order | 10 |
| 22 | 3450065-T0301 Cap | Cap | 3 | $0.61 | Obsolete | View Details |
| 23 | T2040061 Washer Upper Yoke | Washer Upper Yoke | 1 | $7.60 | Available to order | 1 |
| 24 | T2040060 Nut | Nut | 1 | $25.75 | Available to order | 1 |
| 25 | T2040081 O Ring, Fork Seal | O Ring, Fork Seal | 2 | $3.82 | Available to order | 2 |
| 26 | 2040173-T0301 Seal kit | Seal kit | 2 | $35.43 | Available to order | 2 |
| 27 | 3450010-T0301 Plug, Rubber, M8 | Plug, Rubber, M8 | 4 | $1.36 | Obsolete | View Details |
| 28 | 2040225-T0301 Adjuster nut | Adjuster nut PART NO LONGER AVAILABLE » 43916 Lower | 1 | $5.88 | Obsolete | View Details |
| 28 | T2040259 Cover, Headstock Assy | Cover, Headstock Assy 43917 » Lower | 1 | $25.23 | Available to order | 1 |
| 29 | T2140210 Adjuster Nut, Upper | Adjuster Nut, Upper | 1 | $3.61 | Available to order | 1 |
| 30 | T3450195 Plug, M8, Black | Plug, M8, Black Black | 10 | $0.81 | Available to order | 10 |
| 31 | T3900405 Badge | Badge 9083 » | 1 | $23.07 | Available to order | 1 |
| 31 | T3900406 Badge | Badge Special Edition Daytona 1200 | 1 | $66.07 | Obsolete | View Details |
| 32 | T3300090 Rivet | Rivet 9083 » | 1 | $1.18 | Available to order | 1 |
| 33 | T3550405 Washer, M8 x 17 x 1.6 | Washer, M8 x 17 x 1.6 35372 » | 4 | $0.95 | Available to order | 4 |
