Rear Suspension Linkage Double sided swingarm
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2050046 Drag link | Drag link Includes seals & bearings | 1 | $62.05 | Obsolete | View Details |
| 2 | T3330278 Screw, Torx M12 x 155 | Screw, Torx M12 x 155 | 2 | $9.83 | Obsolete | View Details |
| 3 | T3550614 Washer, 12 x 23 x 2 | Washer, 12 x 23 x 2 | 1 | $0.97 | Available to order | 1 |
| 4 | T3550615 Washer, Thrust, 12 x 32 x 1 | Washer, Thrust, 12 x 32 x 1 | 2 | $5.01 | Backorder — Early August 2026 | 2 |
| 5 | T3600040 Seal | Seal | 6 | $6.94 | Available to order | 6 |
| 6 | T3800060 Bearing, Needle Roller, 202620 | Bearing, Needle Roller, 202620 | 5 | $37.15 | Available to order | 5 |
| 7 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 | 2 | $6.07 | Available to order | 2 |
| 8 | T2057348 Sleeve, Dia 20.0 x 118.0 | Sleeve, Dia 20.0 x 118.0 | 2 | $40.22 | Available to order | 2 |
| 9 | T2050061 Sleeve | Sleeve | 1 | $8.83 | Obsolete | View Details |
| 10 | T3202329 Bolt, Torx, M10 x 65, Slv | Bolt, Torx, M10 x 65, Slv | 3 | $8.46 | Available to order | 3 |
| 11 | T3350250 Locknut, Flanged, M10 | Locknut, Flanged, M10 | 3 | $4.16 | Available to order | 3 |
| 12 | T2050050 Drop link | Drop link | 2 | $132.46 | Obsolete | View Details |
