Throttles/Injectors and Fuel Rails
Parts (30)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1244200 Throttle Body Assy | Throttle Body Assy 201542 > | 1 | $2993.19 | Obsolete | View Details |
| 1 | T1244000 Throttle body | Throttle body > 201541 | 1 | $2677.05 | Obsolete | View Details |
| 2 | T1244001 Fuel rail | Fuel rail 201542 > | 1 | $151.80 | Obsolete | View Details |
| 3 | T1244002 Fuel injector | Fuel injector | 4 | $176.63 | Obsolete | View Details |
| 4 | T1245009 Cap, Vacuum Connection | Cap, Vacuum Connection | 4 | $5.05 | Available to order | 4 |
| 5 | T1244006 Sensor | Sensor Throttle position | 1 | $172.10 | Available to order | 1 |
| 6 | T1244007 Stepper motor | Stepper motor | 1 | $151.94 | Backorder — Mid October 2026 | 1 |
| 7 | T1244012 Pressure regulator | Pressure regulator > 201541 | 1 | $70.12 | Obsolete | View Details |
| 8 | T1244201 Fuel Feed Joint Kit | Fuel Feed Joint Kit 201542 > | 1 | $109.94 | Obsolete | View Details |
| 8 | T1244004 Fuel hose assembly | Fuel hose assembly Feed > 201541 | 1 | $123.81 | Obsolete | View Details |
| 9 | T1244013 Fuel hose assembly | Fuel hose assembly Return > 201541 | 1 | $104.08 | Obsolete | View Details |
| 10 | T1244017 Sensor | Sensor Throttle position | 1 | $135.87 | Obsolete | View Details |
| 11 | T1244015 Joint | Joint Fuel feed > 201541 | 1 | $22.81 | Obsolete | View Details |
| 12 | T1244016 Link | Link | 1 | $16.35 | Obsolete | View Details |
| 13 | T1244019 Bracket | Bracket Throttle Cable | 1 | $17.52 | Obsolete | View Details |
| 14 | T1244008 Rubber | Rubber | 4 | $14.50 | Available to order | 4 |
| 15 | T3700073 Clip, Throttle Body to Rubber | Clip, Throttle Body to Rubber | 4 | $12.48 | Available to order | 4 |
| 16 | T3600084 O ring | O ring | 4 | $11.84 | Available to order | 4 |
| 17 | T3330334 Screw, Tx, Pan/Hd, M6 x 16, Slv | Screw, Tx, Pan/Hd, M6 x 16, Slv | 8 | $2.79 | Available to order | 8 |
| 18 | T1244010 Bracket | Bracket | 1 | $52.38 | Obsolete | View Details |
| 19 | T3330891 Bolt, RHHF, M5 x 0.8 x 12, S5041 | Bolt, RHHF, M5 x 0.8 x 12, S5041 | 2 | $3.45 | Available to order | 2 |
| 20 | T3555007 Spring Washer, M5 | Spring Washer, M5 | 2 | $1.50 | Available to order | 2 |
| 21 | T1244025 Ring | Ring | 4 | $4.30 | Obsolete | View Details |
| 22 | T1244102 O ring | O ring | 2 | $2.46 | Obsolete | View Details |
| 23 | T1244023 Seal injector | Seal injector | 4 | $3.93 | Available to order | 4 |
| 24 | T1244024 O Ring, Injector | O Ring, Injector | 4 | $4.15 | Available to order | 4 |
| 25 | T1241225 Spares Kit, CPC, 10mm, Red | Spares Kit, CPC, 10mm, Red 10mm | 1 | $31.16 | Available to order | 1 |
| 26 | T1241165 CPC Kit, White, 8mm Replaced by T1241483 — Kit, Connector, fuel, 6.0 | CPC Kit, White, 8mm 8mm | 1 | $55.98 | Unavailable | View Details |
| 27 | T1244005 Actuator Assembly | Actuator Assembly | 1 | $153.73 | Obsolete | View Details |
| 28 | T3700262 Clip, Hose, Dia 15.5-17.0 | Clip, Hose, Dia 15.5-17.0 Part of Fuel Connector Kit > 188867 | 1 | $4.38 | Out of Stock | Notify Me |
