Front Forks and Yokes
Parts (43)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2044413 Stanchion Assy, LH | Stanchion Assy, LH | 1 | $742.57 | Obsolete | View Details |
| 2 | T2044414 Stanchion assembly | Stanchion assembly RH | 1 | $742.57 | Obsolete | View Details |
| 3 | T2045550 Top cap | Top cap | 2 | $44.87 | Obsolete | View Details |
| 4 | T2040081 O Ring, Fork Seal | O Ring, Fork Seal | 2 | $3.59 | Available to order | 2 |
| 5 | T2045551 Spring washer | Spring washer | 2 | $2.56 | Obsolete | View Details |
| 6 | T2045553 Spring | Spring | 2 | $75.88 | Obsolete | View Details |
| 7 | T2045552 Nut | Nut | 2 | $1.76 | Obsolete | View Details |
| 8 | T2045554 Cylinder | Cylinder | 2 | $373.89 | Obsolete | View Details |
| 9 | T2045558 Inner tube | Inner tube | 2 | $242.91 | Obsolete | View Details |
| 10 | T2040321 Snap ring | Snap ring | 2 | $5.10 | Obsolete | View Details |
| 11 | T2040320 Valve | Valve | 2 | $17.38 | Obsolete | View Details |
| 12 | T2045557 Bearing | Bearing | 2 | $11.12 | Available to order | 2 |
| 13 | T2045555 Oil lock | Oil lock | 2 | $27.83 | Obsolete | View Details |
| 14 | T2040323 Dust Seal | Dust Seal | 2 | $20.03 | Available to order | 2 |
| 15 | 2040079-T0301 Ring snap | Ring snap | 2 | $6.83 | Available to order | 2 |
| 16 | T2045556 Oil seal | Oil seal | 2 | $21.36 | Available to order | 2 |
| 17 | 2040077-T0301 Washer | Washer | 2 | $3.74 | Obsolete | View Details |
| 18 | T2045559 Sliding bush | Sliding bush | 1 | $14.58 | Available to order | 1 |
| 19 | T2045561 Tube outer | Tube outer LH | 1 | $378.04 | Obsolete | View Details |
| 20 | T2045560 Tube outer | Tube outer RH | 1 | $378.04 | Obsolete | View Details |
| 21 | 2040074-T0301 Sealing washer | Sealing washer | 2 | $1.13 | Available to order | 2 |
| 22 | 2040075-T0301 Capscrew | Capscrew PART NO LONGER AVAILABLE | 2 | $19.42 | Obsolete | View Details |
| 23 | T3050133 Capscrew | Capscrew M8 x 35mm | 2 | $4.55 | Backorder — Early October 2026 | 2 |
| 24 | T2044003 Lower Yoke Assy | Lower Yoke Assy Daytona 650 | 1 | $399.66 | Obsolete | View Details |
| 24 | T2044425 Yoke assembly | Yoke assembly Lower Daytona 600 | 1 | $399.66 | Obsolete | View Details |
| 25 | T3800052 Bearing, Sac, 55 x 30 x 17 | Bearing, Sac, 55 x 30 x 17 Daytona 650 | 1 | $33.95 | Available to order | 1 |
| 25 | T3800047 Bearing taper roller | Bearing taper roller Daytona 600 | 1 | $98.72 | Available to order | 1 |
| 26 | A9910053 Capscrew | Capscrew M8 x 30mm s/s | 4 | $1.15 | Obsolete | View Details |
| 27 | T2040535 Cover, Headstock Assy | Cover, Headstock Assy Daytona 650 | 1 | $23.35 | Available to order | 1 |
| 27 | T2040259 Cover, Headstock Assy | Cover, Headstock Assy Daytona 600 | 1 | $24.33 | Out of Stock | Notify Me |
| 28 | T2044002 Yoke, Upper Assy | Yoke, Upper Assy Daytona 650 | 1 | $259.83 | Obsolete | View Details |
| 28 | T2044419 Yoke assembly | Yoke assembly Upper Daytona 600 | 1 | $188.79 | Obsolete | View Details |
| 29 | T3050132 Screw, Skt Hd, Ss | Screw, Skt Hd, Ss M8 x 25mm s/s | 2 | $3.50 | Available to order | 2 |
| 30 | T2040061 Washer Upper Yoke | Washer Upper Yoke | 1 | $7.14 | Available to order | 1 |
| 31 | T2040345 Nut, Upper Yoke | Nut, Upper Yoke | 1 | $19.05 | Obsolete | View Details |
| 32 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 2 | $0.89 | Available to order | 2 |
| 33 | T2042943 Shroud, Fork, LH | Shroud, Fork, LH LH | 1 | $42.57 | Backorder — Mid August 2026 | 1 |
| 34 | T2042944 Shroud, Fork, RH | Shroud, Fork, RH RH | 1 | $42.57 | Available to order | 1 |
| 35 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 2 | $3.50 | Available to order | 2 |
| 36 | T2701237 Kit, Reflector, Amber | Kit, Reflector, Amber US and CA - Kit Contains 2 Reflectors | 1 | $28.41 | Out of Stock | Notify Me |
| 37 | T2040545 Adjuster Nut | Adjuster Nut Daytona 650 - * PART NO LONGER AVAILABLE * | 1 | $6.61 | Obsolete | View Details |
| 38 | T3551820 Locating Washer, 25.5x38x2, Slv | Locating Washer, 25.5x38x2, Slv Daytona 650 | 1 | $1.72 | Available to order | 1 |
| 39 | T3700139 Guide, Brake Hose | Guide, Brake Hose Daytona 650 | 1 | $4.90 | Obsolete | View Details |
