Engine Management System
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1299304 ECM Base | ECM Base | 1 | $406.03 | Backorder — Late August 2026 | 1 |
| 2 | T3450255 Plug, Retainer, Plastic | Plug, Retainer, Plastic | 2 | $1.40 | Available to order | 2 |
| 3 | T1290038 Sensor | Sensor | 1 | $193.93 | Available to order | 1 |
| 4 | T1290239 O Ring, Crankshaft Sensor | O Ring, Crankshaft Sensor | 1 | $5.30 | Available to order | 1 |
| 5 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 1 | $1.40 | Available to order | 1 |
| 6 | T1290037 Ignition Coil, Plug Top, 4-Cyl | Ignition Coil, Plug Top, 4-Cyl | 4 | $171.11 | Available to order | 4 |
| 7 | T1290023 Spark plug | Spark plug | 4 | $17.50 | Available to order | 4 |
| 8 | T1293000 Sensor, Road Speed | Sensor, Road Speed Road speed | 1 | $237.62 | Available to order | 1 |
| 9 | T1297000 Sensor, Air Temperature | Sensor, Air Temperature Air temperature | 1 | $57.48 | Available to order | 1 |
| 10 | T1292015 Air Pressure Sensor | Air Pressure Sensor Air pressure | 2 | $142.58 | Available to order | 2 |
| 11 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 M6 | 1 | $0.67 | Available to order | 1 |
| 12 | T1291900 Hose | Hose Map sensor | 1 | $2.40 | Obsolete | View Details |
| 13 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 1 | $1.72 | Available to order | 1 |
| 14 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 1 | $4.55 | Available to order | 1 |
