Front Mudguard
Parts (9)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2310214-PM Front Mudguard, Sapphire Black | Front Mudguard, Sapphire Black Fitted to Red and White Bikes | 1 | $311.32 | Available to order | 1 |
| 1 | T2310214-QB Front Mudguard, Satin Jet Black | Front Mudguard, Satin Jet Black Fitted to Grey/Black Bikes | 1 | $311.32 | Available to order | 1 |
| 2 | T2320002 Fork Protector, Fork, LH | Fork Protector, Fork, LH | 1 | $47.56 | Backorder — Mid August 2026 | 1 |
| 3 | T2320003 Fork Protector, Fork, RH | Fork Protector, Fork, RH | 1 | $47.56 | Available to order | 1 |
| 4 | T3330312 Screw, But/Hd, M6 x 20, Slv | Screw, But/Hd, M6 x 20, Slv | 4 | $3.59 | Backorder — Late August 2026 | 4 |
| 5 | T3330945 Screw, But/Hd, M5 x 16, Blk | Screw, But/Hd, M5 x 16, Blk | 2 | $8.46 | Available to order | 2 |
| 6 | T3351002 Nut, Captive, U-Type, M5, Slv | Nut, Captive, U-Type, M5, Slv | 2 | $2.37 | Available to order | 2 |
| 7 | T2312541 Decal, Front Mudguard | Decal, Front Mudguard Fitted to T2310214-QB Mudguard | 1 | $28.53 | Available to order | 1 |
| 7 | T2311051 Decal, Front Mudguard, Centre | Decal, Front Mudguard, Centre Fitted to T2310214-PM Mudguard | 1 | $31.95 | Available to order | 1 |
