Electrical System
Parts (48)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2505709 Main Harness | Main Harness | 1 | $907.17 | Available to order | 1 |
| 1a | T2501305 Fuse, Mini, 5A | Fuse, Mini, 5A | 1 | $5.05 | Available to order | 1 |
| 1a | T2501315 Fuse, Mini, 15A | Fuse, Mini, 15A | 1 | $5.05 | Available to order | 1 |
| 1a | T2505093 Fuse, Mini, 3A | Fuse, Mini, 3A | 1 | $0.95 | Out of Stock | Notify Me |
| 2 | T1290975 Air Pressure Sensor | Air Pressure Sensor | 1 | $139.14 | Available to order | 1 |
| 3 | T3050346 Screw, Cap/Hd, M5 x 20, Slv | Screw, Cap/Hd, M5 x 20, Slv | 1 | $2.63 | Available to order | 1 |
| 4 | T1310120 Starter, Solenoid, Fused | Starter, Solenoid, Fused | 1 | $61.20 | Available to order | 1 |
| 4a | T2500805 Fuse, 30A | Fuse, 30A | 1 | $1.50 | Available to order | 1 |
| 5 | T3205077 Bolt, HHF, Lghtd, M6 x 8, Slv | Bolt, HHF, Lghtd, M6 x 8, Slv | 2 | $5.20 | Available to order | 2 |
| 6 | T2502455 Fall Detection Switch | Fall Detection Switch | 1 | $83.02 | Available to order | 1 |
| 7 | T3330390 Screw, H/Hd, M4 x 25, Slv, Enc | Screw, H/Hd, M4 x 25, Slv, Enc | 2 | $2.91 | Available to order | 2 |
| 8 | T2506311 Horn Assy, 440 Hz | Horn Assy, 440 Hz All Except IN | 1 | $56.47 | Available to order | 1 |
| 8 | T2500113 Horn Assembly, Hi Tone | Horn Assembly, Hi Tone IN Only | 1 | $41.82 | Available to order | 1 |
| 9 | T2500183 Battery | Battery All Markets Except EF/ER/GR/BR/JP | 1 | $120.70 | Available to order | 1 |
| 9 | T2504606 Spares Kit, Battery | Spares Kit, Battery BR Only | 1 | $125.73 | Out of Stock | Notify Me |
| 9 | T2507071 Battery Kit | Battery Kit JP Only - Includes Pad, Item 39 | 1 | $136.98 | Out of Stock | Notify Me |
| 9 | T2506715 Kit, Battery, YTX9-BS | Kit, Battery, YTX9-BS EF/ER/GR Markets Only | 1 | $120.70 | Out of Stock | Notify Me |
| 10 | T2501789 Battery Strap | Battery Strap | 1 | $11.24 | Available to order | 1 |
| 11 | T2503437 Auxilary Fly Lead, JP | Auxilary Fly Lead, JP JP Only | 1 | $24.88 | Available to order | 1 |
| 12 | T2503688 Mldg, Harness Retention, RHS | Mldg, Harness Retention, RHS | 1 | $20.23 | Available to order | 1 |
| 13 | T2503699 Mldg, Harness Retention, LHS | Mldg, Harness Retention, LHS | 1 | $20.23 | Available to order | 1 |
| 14 | T2502698 Edge Protector, Headstock | Edge Protector, Headstock | 3 | $9.86 | Backorder — Mid October 2026 | 3 |
| 15 | T2503828 Bracket, O2 Sensor | Bracket, O2 Sensor | 1 | $8.30 | Out of Stock | Notify Me |
| 16 | T2503998 Bracket, Harness, Hego Sensor | Bracket, Harness, Hego Sensor | 1 | $8.30 | Out of Stock | Notify Me |
| 17 | T2504880 Guide, Headstock Rubber | Guide, Headstock Rubber | 1 | $13.37 | Available to order | 1 |
| 18 | T2505073 Lead, Starter | Lead, Starter | 1 | $24.88 | Available to order | 1 |
| 19 | T2505778 Lead, Battery, Positive | Lead, Battery, Positive | 1 | $12.62 | Available to order | 1 |
| 20 | T2505779 Earth Lead | Earth Lead | 1 | $27.93 | Backorder — Mid October 2026 | 1 |
| 21 | T2507729 Relay, Ultra Micro, ISO 280 | Relay, Ultra Micro, ISO 280 | 6 | $8.02 | Available to order | 6 |
| 22 | T2508250 Tab, Connector, Crank Pos | Tab, Connector, Crank Pos | 1 | $10.19 | Backorder — Mid October 2026 | 1 |
| 23 | T2508991 Subharness, N/plat | Subharness, N/plat | 1 | $47.56 | Available to order | 1 |
| 24 | T2505889 ECU Cover | ECU Cover | 1 | $21.08 | Out of Stock | Notify Me |
| 25 | T3020054 Grommet, Sidepanel | Grommet, Sidepanel | 2 | $2.53 | Out of Stock | Notify Me |
| 26 | T2510000 Engine Subharness | Engine Subharness | 1 | $79.13 | Available to order | 1 |
| 27 | T3100050 Stud, M6 x 28, Enc | Stud, M6 x 28, Enc | 2 | $3.93 | Available to order | 2 |
| 28 | T3330943 Screw, But/Hd, M5 x 14, Slv | Screw, But/Hd, M5 x 14, Slv | 8 | $5.24 | Available to order | 8 |
| 29 | T3331625 Screw, Btn Hd, M8 x 12, Slv | Screw, Btn Hd, M8 x 12, Slv | 1 | $1.84 | Available to order | 1 |
| 30 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 | 2 | $0.71 | Available to order | 2 |
| 31 | T3350161 Nut, Captive, M5 | Nut, Captive, M5 | 9 | $4.84 | Available to order | 9 |
| 32 | T3351093 Nut, Captive, M4 | Nut, Captive, M4 | 2 | $4.84 | Available to order | 2 |
| 33 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 7 | $0.95 | Available to order | 7 |
| 34 | T3700016 Cable Tie, 370 Long | Cable Tie, 370 Long | 1 | $1.01 | Available to order | 1 |
| 35 | T3700212 Band, Rubber | Band, Rubber | 4 | $3.50 | Available to order | 4 |
| 36 | T3700259 Rubber Band, 43mm | Rubber Band, 43mm | 5 | $4.15 | Available to order | 5 |
| 37 | T3700288 Edge Clip, Harness, Flared | Edge Clip, Harness, Flared | 2 | $1.97 | Available to order | 2 |
| 38 | T3704444 Clip, Cable Tie, Fir Tree | Clip, Cable Tie, Fir Tree | 4 | $2.65 | Backorder — Early October 2026 | 4 |
| 39 | T2509978 Pad, Battery | Pad, Battery JP Only - Included in Battery Kit, Item 9 | 1 | $9.81 | Available to order | 1 |
| 40 | T2505049 Blanking Plug, O2 Sensor | Blanking Plug, O2 Sensor Not Illustrated | 1 | $7.08 | Available to order | 1 |
