Evap System
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2409017 Carbon Cannister, 137mm Length | Carbon Cannister, 137mm Length | 1 | $107.98 | Available to order | 1 |
| 2 | T3700016 Cable Tie, 370 Long | Cable Tie, 370 Long | 1 | $1.01 | Available to order | 1 |
| 3 | T1248990 Purge Valve | Purge Valve | 1 | $65.30 | Available to order | 1 |
| 4 | T1292075 Hose, Throttle Body, Cyl 1 | Hose, Throttle Body, Cyl 1 | 1 | $3.45 | Available to order | 1 |
| 5 | T1292076 Hose, Throttle Body, Cyl 2 | Hose, Throttle Body, Cyl 2 | 1 | $3.45 | Available to order | 1 |
| 6 | T1292077 Hose, Throttle Body, Cyl 3 | Hose, Throttle Body, Cyl 3 | 1 | $3.45 | Available to order | 1 |
| 7 | T1242929 Connector, 4 Way | Connector, 4 Way | 1 | $11.31 | Available to order | 1 |
| 8 | T1241890 Restrictor, Purge, Evap | Restrictor, Purge, Evap | 4 | $11.75 | Available to order | 4 |
| 9 | T2409145 Hose, Tank to Evap | Hose, Tank to Evap | 1 | $18.69 | Out of Stock | Notify Me |
| 10 | T2409140 Hose, Canister to Valve | Hose, Canister to Valve | 1 | $34.12 | Backorder — Late September 2026 | 1 |
| 11 | T2403696 Hose, Evap, Breather | Hose, Evap, Breather | 1 | $28.53 | Out of Stock | Notify Me |
| 12 | T2409147 Hose, Purge to Manifold | Hose, Purge to Manifold | 1 | $15.15 | Out of Stock | Notify Me |
| 13 | T2403697 Hose, Evap, Drain Upper | Hose, Evap, Drain Upper | 1 | $38.04 | Out of Stock | Notify Me |
| 14 | T2103011 Spigot, Straight | Spigot, Straight | 1 | $9.57 | Available to order | 1 |
| 15 | T2403714 Hose, Evap, Drain Lower | Hose, Evap, Drain Lower | 1 | $38.04 | Out of Stock | Notify Me |
| 16 | T2409146 Bracket, Purge Valve | Bracket, Purge Valve | 1 | $8.30 | Out of Stock | Notify Me |
| 17 | T2403644 Bracket, Fuel Hose, Mldg | Bracket, Fuel Hose, Mldg | 1 | $10.14 | Backorder — Early October 2026 | 1 |
| 18 | T3331063 Bolt, But/Hd, M5 x 17, Slv | Bolt, But/Hd, M5 x 17, Slv | 1 | $2.31 | Available to order | 1 |
| 19 | T3332568 Screw, But/HD, M5 x 8, Slv | Screw, But/HD, M5 x 8, Slv | 1 | $4.15 | Available to order | 1 |
| 20 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc | 1 | $1.50 | Available to order | 1 |
| 21 | T3700072 Cable Clip, Dia 15-16mm BK | Cable Clip, Dia 15-16mm BK | 1 | $4.38 | Available to order | 1 |
| 22 | T2040811 Twin Clip, Brake Hose | Twin Clip, Brake Hose | 1 | $2.79 | Available to order | 1 |
| 23 | T3700233 Clip, Brake Hose | Clip, Brake Hose | 1 | $6.27 | Available to order | 1 |
| 24 | T3700259 Rubber Band, 43mm | Rubber Band, 43mm | 1 | $4.15 | Available to order | 1 |
