Footrests & Mountings
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2083382 Control Plate, RH | Control Plate, RH | 1 | $92.29 | Available to order | 1 |
| 2 | T2083381 Control Plate, LH | Control Plate, LH | 1 | $92.29 | Available to order | 1 |
| 3 | T2081936 Heelguard, RH | Heelguard, RH | 1 | $49.41 | Available to order | 1 |
| 4 | T2081935 Heelguard, LH | Heelguard, LH | 1 | $50.37 | Available to order | 1 |
| 5 | T2082103 Footrest, Front, RH | Footrest, Front, RH | 1 | $75.74 | Available to order | 1 |
| 6 | T2082102 Footrest, Front, LH | Footrest, Front, LH | 1 | $75.74 | Available to order | 1 |
| 7 | T2085164 Peg, Bank Angle, 9.2mm | Peg, Bank Angle, 9.2mm | 2 | $14.07 | Available to order | 2 |
| 8 | T3205064 Bolt, RHHF, Domed, S/S, M6 x 16, Enc | Bolt, RHHF, Domed, S/S, M6 x 16, Enc | 2 | $4.01 | Out of Stock | Notify Me |
| 9 | T2080546 Pin, Pivot, Footrest | Pin, Pivot, Footrest | 2 | $6.55 | Available to order | 2 |
| 10 | T2080819 Return Spring, Footrest | Return Spring, Footrest | 2 | $6.29 | Available to order | 2 |
| 11 | T3500207 Circlip, Ext 8 X 0.89 | Circlip, Ext 8 X 0.89 | 2 | $2.85 | Available to order | 2 |
| 12 | T3050321 Screw, Cap/Hd, M8 x 20, Slv | Screw, Cap/Hd, M8 x 20, Slv | 4 | $7.42 | Available to order | 4 |
