Evaporative Loss Control System
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1292075 Hose, Throttle Body, Cyl 1 | Hose, Throttle Body, Cyl 1 | 1 | $3.24 | Available to order | 1 |
| 2 | T1292076 Hose, Throttle Body, Cyl 2 | Hose, Throttle Body, Cyl 2 | 1 | $3.24 | Out of Stock | Notify Me |
| 3 | T1292077 Hose, Throttle Body, Cyl 3 | Hose, Throttle Body, Cyl 3 | 1 | $3.24 | Available to order | 1 |
| 4 | T1242929 Connector, 4 Way | Connector, 4 Way | 1 | $10.90 | Available to order | 1 |
| 5 | T1241890 Restrictor, Purge, Evap | Restrictor, Purge, Evap | 3 | $11.32 | Available to order | 3 |
| 6 | T1248990 Purge Valve | Purge Valve | 1 | $66.52 | Available to order | 1 |
| 7 | T2403000 Carbon Canister | Carbon Canister | 1 | $100.76 | Available to order | 1 |
| 8 | T3700077 Clip, 10.5 Rer Oetiker | Clip, 10.5 Rer Oetiker | 1 | $4.01 | Available to order | 1 |
| 9 | T1245099 Formed Hose, Can to Purge | Formed Hose, Can to Purge | 1 | $27.34 | Out of Stock | Notify Me |
| 10 | T1242586 Hose, Evap, Vent | Hose, Evap, Vent | 1 | $23.00 | Available to order | 1 |
| 11 | T1240311 Hose, Evap, Purge | Hose, Evap, Purge | 1 | $5.69 | Out of Stock | Notify Me |
| 12 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 2 | $1.72 | Available to order | 2 |
| 13 | T2402424 Wire Guide, Evap System | Wire Guide, Evap System | 1 | $8.09 | Available to order | 1 |
| 14 | T3330726 Screw, Btn/Hd, M6 x 12, Slv | Screw, Btn/Hd, M6 x 12, Slv | 1 | $4.42 | Available to order | 1 |
| 15 | T3332568 Screw, But/HD, M5 x 8, Slv | Screw, But/HD, M5 x 8, Slv | 1 | $3.90 | Available to order | 1 |
