Instruments Bonneville
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2501457 Speedo Assy, MPH | Speedo Assy, MPH UK, CY, SG, TW & US | 1 | $769.44 | Obsolete | View Details |
| 1 | T2501458 Speedo Assy, KPH | Speedo Assy, KPH All Mkts expt UK, CY, SG, TW & US - F2 | 1 | $739.35 | Out of Stock | Notify Me |
| 2 | T2501192 Speedo mph | Speedo mph UK, CY, SG, TW & US > 308536 | 1 | $302.58 | Obsolete | View Details |
| 2 | T2501453 Speedo Gauge, MPH | Speedo Gauge, MPH * Part No Longer Available * UK, CY, SG, TW & US - 308537 > | 1 | $357.88 | Obsolete | View Details |
| 2 | T2501193 Speedo kph | Speedo kph All Mkts expt UK, CY, SG, TW & US - F4 | 1 | $378.49 | Obsolete | View Details |
| 2 | T2501454 Speedo Gauge, KPH | Speedo Gauge, KPH * PART NO LONGER AVAILABLE * All Mkts expt UK, CY, SG, TW & US - F2 | 1 | $373.98 | Obsolete | View Details |
| 3 | T2501185 Housing speedo | Housing speedo | 1 | $163.49 | Available to order | 1 |
| 4 | T2501188 Washer | Washer | 4 | $1.27 | Available to order | 4 |
| 5 | T2501189 Domed nut | Domed nut | 2 | $2.25 | Backorder — Late August 2026 | 2 |
| 6 | T2502089 Bulb, T10 12v 1.7w | Bulb, T10 12v 1.7w 12V, 1.7W, 10mm Dia | 1 | $2.74 | Available to order | 1 |
| 7 | 2500085-T0301 Bulb | Bulb 12V, 1.7W, 6.5mm Dia | 5 | $5.60 | Available to order | 5 |
| 8 | T2501202 Instrument panel | Instrument panel | 1 | $43.28 | Available to order | 1 |
| 9 | T2501203 Rubber damper | Rubber damper | 1 | $17.56 | Available to order | 1 |
| 10 | T2501204 Reset knob | Reset knob | 1 | $7.62 | Available to order | 1 |
| 11 | T2501205 Screw, Reset Knob | Screw, Reset Knob | 1 | $1.40 | Available to order | 1 |
| 12 | T2501206 Harness | Harness | 1 | $98.85 | Out of Stock | Notify Me |
| 13 | T2501207 Cover | Cover Light Unit | 1 | $63.70 | Available to order | 1 |
| 15 | T2501209 Lens | Lens Indicator | 1 | $14.47 | Available to order | 1 |
| 16 | T2501210 Lens | Lens High Beam | 1 | $10.34 | Available to order | 1 |
| 17 | T2501211 Lens | Lens Oil Warning | 1 | $10.34 | Available to order | 1 |
| 18 | T2501212 Lens | Lens Neutral | 1 | $22.21 | Available to order | 1 |
| 19 | T2501216 Screw | Screw | 2 | $1.62 | Available to order | 2 |
| 20 | T2501217 Plug | Plug | 1 | $2.38 | Obsolete | View Details |
| 21 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 4 | $3.50 | Available to order | 4 |
