Instruments Bonneville T100
Parts (30)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2501451 Instrument Assy, MPH | Instrument Assy, MPH UK,CY,SG,TW & US | 1 | $930.46 | Obsolete | View Details |
| 1 | T2501452 Instrument Assy, KPH | Instrument Assy, KPH All markets except UK,CY,SG,TW & US | 1 | $1040.33 | Obsolete | View Details |
| 2 | T2501282 SPEEDO GAUGE,MPH | SPEEDO GAUGE,MPH UK,CY,SG,TW & US; F2 -All Vins/F4 >289961 | 1 | $249.18 | Obsolete | View Details |
| 2 | T2501453 Speedo Gauge, MPH | Speedo Gauge, MPH * Part No Longer Available * F4 - 289962 > | 1 | $357.88 | Obsolete | View Details |
| 2 | T2501283 SPEEDO GAUGE,KPH | SPEEDO GAUGE,KPH All mkts except UK,CY,SG,TW&US; >289680-F2/>293000-F4 | 1 | $278.60 | Obsolete | View Details |
| 2 | T2501454 Speedo Gauge, KPH | Speedo Gauge, KPH * PART NO LONGER AVAILABLE * All mkts except UK,CY,SG,TW&US; F2-289681>/F4-293001> | 1 | $373.98 | Obsolete | View Details |
| 3 | T2501185 Housing speedo | Housing speedo | 1 | $163.49 | Available to order | 1 |
| 4 | T2501223 Tachometer | Tachometer F2 MPH Inst Assy ALL Vins; F4 MPH Inst Assy >289961; F2 KPH Inst Assy >289680; F4 KPH Inst Assy >293000 | 1 | $351.15 | Obsolete | View Details |
| 4 | T2503118 Tacho Gauge | Tacho Gauge F4 MPH Inst Assy 289962>; F2 KPH Inst Assy 289681>; F4 KPH Inst Assy 293001> | 1 | $319.83 | Obsolete | View Details |
| 5 | T2501186 Housing tacho | Housing tacho | 1 | $163.49 | Available to order | 1 |
| 6 | T2501188 Washer | Washer | 8 | $1.27 | Available to order | 8 |
| 7 | T2501189 Domed nut | Domed nut | 4 | $2.25 | Backorder — Late August 2026 | 4 |
| 8 | T2502089 Bulb, T10 12v 1.7w | Bulb, T10 12v 1.7w 12V, 1.7W, 10mm Dia | 3 | $2.74 | Available to order | 3 |
| 9 | 2500085-T0301 Bulb | Bulb 12V, 1.7W, 6.5mm Dia | 5 | $5.60 | Available to order | 5 |
| 10 | T2501213 Pressing, Instruments | Pressing, Instruments | 1 | $39.92 | Available to order | 1 |
| 11 | T2501203 Rubber damper | Rubber damper | 1 | $17.56 | Available to order | 1 |
| 12 | T2503839 Damper Ring | Damper Ring | 1 | $17.11 | Available to order | 1 |
| 13 | T2501172 Knob, Trip, Speedometer | Knob, Trip, Speedometer | 1 | $9.49 | Available to order | 1 |
| 14 | T2501205 Screw, Reset Knob | Screw, Reset Knob | 1 | $1.40 | Available to order | 1 |
| 15 | T2501225 Supplementary harness | Supplementary harness | 1 | $192.02 | Available to order | 1 |
| 16 | T2501255 COVER,LIGHT UNIT | COVER,LIGHT UNIT Light Unit | 1 | $59.87 | Available to order | 1 |
| 18 | T2501209 Lens | Lens Indicator | 1 | $14.47 | Available to order | 1 |
| 19 | T2501210 Lens | Lens High Beam | 1 | $10.34 | Available to order | 1 |
| 20 | T2501211 Lens | Lens Oil Warning | 1 | $10.34 | Available to order | 1 |
| 21 | T2501212 Lens | Lens Neutral | 1 | $22.21 | Available to order | 1 |
| 22 | T2501216 Screw | Screw | 2 | $1.62 | Available to order | 2 |
| 23 | T2501227 Plug | Plug | 1 | $2.95 | Available to order | 1 |
| 24 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 4 | $3.50 | Available to order | 4 |
| 25 | T2501226 Screw | Screw M4 x 12mm | 2 | $1.62 | Available to order | 2 |
| 26 | T2501214 Holder | Holder Warning light | 1 | $13.70 | Obsolete | View Details |
