Motor
Parts (9)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T5100029 BLDC Motor Assy, LC, 50V, 1600W | BLDC Motor Assy, LC, 50V, 1600W | 1 | $759.90 | Out of Stock | Notify Me |
| 2 | T5100027 Encoder Assy, Gasket Type | Encoder Assy, Gasket Type Please see Service Bulletin 'OSET Bulletin OB-005 - TXP Encoder Replacement' before ordering. | 1 | $14.64 | Out of Stock | Notify Me |
| 3 | T5100026 Gasket, Encoder, Mldg, Blk | Gasket, Encoder, Mldg, Blk Please see Service Bulletin 'OSET Bulletin OB-005 - TXP Encoder Replacement' before ordering. | 1 | $11.54 | Available to order | 1 |
| 4 | TOS30069 Bolt,M6X14Mm,Cap+Wash,10.9,Blk | Bolt,M6X14Mm,Cap+Wash,10.9,Blk | 4 | $1.76 | Out of Stock | Notify Me |
| 5 | TOS30046 Bolt, M5X30Mm, Cap, Captive, Blk | Bolt, M5X30Mm, Cap, Captive, Blk | 2 | $2.47 | Available to order | 2 |
| 6 | T1180529 Guard,Sprocket,Front,Lrg,Blk | Guard,Sprocket,Front,Lrg,Blk | 1 | $13.53 | Available to order | 1 |
| 7 | TOS30036 Circlip, External D1400-0140 | Circlip, External D1400-0140 | 1 | $2.68 | Available to order | 1 |
| 8 | T1180599 Front Sprocket, 11T, Spline | Front Sprocket, 11T, Spline | 1 | $22.58 | Available to order | 1 |
| 9 | TOS30063 Snap Ring, M2400-15, Steel | Snap Ring, M2400-15, Steel | 1 | $0.92 | Out of Stock | Notify Me |
