Clutch Vin 210262 >
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1170070 Clutch Assembly | Clutch Assembly | 1 | $1833.88 | Obsolete | View Details |
| 2 | T1170071 Outer Drum Assy, Clutch | Outer Drum Assy, Clutch | 1 | $642.93 | Obsolete | View Details |
| 3 | T1170297 Sleeve, Sprocket | Sleeve, Sprocket | 1 | $45.97 | Obsolete | View Details |
| 4 | T1170078 Sprocket, Auxillary Drive | Sprocket, Auxillary Drive | 1 | $92.70 | Obsolete | View Details |
| 5 | T1170012 Bush, Clutch | Bush, Clutch | 1 | $25.05 | Obsolete | View Details |
| 6 | T1170075 Washer | Washer | 1 | $5.04 | Obsolete | View Details |
| 7 | T1174400 Disc, Friction, Clutch A | Disc, Friction, Clutch A | 5 | $29.97 | Available to order | 5 |
| 7 | T1170107 Clutch Friction Disc A Multipack (10) | Clutch Friction Disc A Multipack (10) | 1 | $193.73 | Obsolete | View Details |
| 8 | T1170276 Disc, Friction, Clutch A | Disc, Friction, Clutch A | 1 | $29.97 | Available to order | 1 |
| 9 | T1170277 Plate, Clutch | Plate, Clutch | 6 | $22.92 | Available to order | 6 |
| 10 | T1170278 Disc, Friction, Clutch B | Disc, Friction, Clutch B | 1 | $46.64 | Available to order | 1 |
| 11 | T1170279 Spring Judder | Spring Judder | 1 | $26.46 | Obsolete | View Details |
| 12 | T1170081 Seat, Judder Spring | Seat, Judder Spring | 1 | $16.68 | Obsolete | View Details |
| 13 | T1170072 Centre, Clutch | Centre, Clutch | 1 | $85.27 | Obsolete | View Details |
| 14 | T1170076 Spring, Clutch | Spring, Clutch | 5 | $5.57 | Obsolete | View Details |
| 15 | T1170074 Plate, Clutch, Pressure | Plate, Clutch, Pressure | 1 | $70.73 | Obsolete | View Details |
| 16 | T1170719 Bolt, M6 X 25 | Bolt, M6 X 25 | 5 | $1.60 | Unavailable | View Details |
| 17 | T1170067 Bearing, Pressure Plate | Bearing, Pressure Plate | 1 | $33.23 | Available to order | 1 |
| 18 | T1171282 Washer, ID 22, OD 34 | Washer, ID 22, OD 34 | 1 | $4.64 | Available to order | 1 |
| 19 | T1170192 Nut, Clutch, M22 | Nut, Clutch, M22 | 1 | $12.29 | Available to order | 1 |
| 20 | T1179999 Washer, C, Clutch | Washer, C, Clutch | 1 | $11.71 | Available to order | 1 |
| 21 | T1170068 Joint Piece, Clutch | Joint Piece, Clutch | 1 | $33.74 | Obsolete | View Details |
