Throttles, Injectors and Fuel Rail
Parts (8)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1243415 Throttle Body Assembly, 3 Cyl | Throttle Body Assembly, 3 Cyl | 1 | $2248.35 | Available to order | 1 |
| 2 | T1243403 Pipe Set, Fuel | Pipe Set, Fuel | 1 | $210.54 | Available to order | 1 |
| 3 | T1243416 Fuel Injector Assy | Fuel Injector Assy | 3 | $219.68 | Available to order | 3 |
| 4 | T1240677 Transition Piece, Rubber, TBody | Transition Piece, Rubber, TBody | 3 | $30.53 | Available to order | 3 |
| 5 | T3701055 Band Clamp, 55mm | Band Clamp, 55mm | 3 | $7.08 | Available to order | 3 |
| 6 | T3331200 Screw, CSK, M6 x 20, T30, SLV, Enc | Screw, CSK, M6 x 20, T30, SLV, Enc | 6 | $7.68 | Available to order | 6 |
| 7 | T1245583 Hose Assy, Fuel Feed, Rubber | Hose Assy, Fuel Feed, Rubber | 1 | $118.98 | Available to order | 1 |
| 8 | T1243420 O Ring | O Ring | 3 | $2.79 | Backorder — Early November 2026 | 3 |
