Fuel Tank
Parts (11)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2402338 Fuel Tank, MX | Fuel Tank, MX | 1 | $354.10 | Available to order | 1 |
| 2 | T2406661 Puck, Fuel Tank | Puck, Fuel Tank | 1 | $5.67 | Available to order | 1 |
| 3 | T2406737 Mount, Fuel Tank, Rubber | Mount, Fuel Tank, Rubber | 2 | $8.52 | Available to order | 2 |
| 4 | T3200666 Bolt, TX, Lgtnd, M6 x 40, Slv | Bolt, TX, Lgtnd, M6 x 40, Slv | 2 | $2.84 | Available to order | 2 |
| 5 | T2403659 Spigot, Tank Mount | Spigot, Tank Mount | 1 | $15.11 | Available to order | 1 |
| 6 | T2406888 Isolation Mat, Rubber | Isolation Mat, Rubber | 1 | $19.12 | Available to order | 1 |
| 7 | T3200663 Bolt, TX, Lghtd, M6 x 20, Slv | Bolt, TX, Lghtd, M6 x 20, Slv | 1 | $2.84 | Available to order | 1 |
| 8 | T3330441 Screw, S/Tap, Shld, Pan/Hd, 6 x 17 | Screw, S/Tap, Shld, Pan/Hd, 6 x 17 | 3 | $13.82 | Available to order | 3 |
| 9 | T3200399 Bolt, TX, M5 x 20, Slv | Bolt, TX, M5 x 20, Slv | 1 | $2.84 | Available to order | 1 |
| 10 | T2406041 Spacer, Conical, Seat Mount | Spacer, Conical, Seat Mount | 1 | $6.74 | Available to order | 1 |
| 11 | T2409045 Tube, Fill Control | Tube, Fill Control | 1 | $6.11 | Available to order | 1 |
