Side Panels
Parts (5)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2313616 Cover, Fuel Tank, LHS | Cover, Fuel Tank, LHS | 1 | $53.29 | Available to order | 1 |
| 2 | T2313618 Cover, Fuel Tank, RHS | Cover, Fuel Tank, RHS | 1 | $53.29 | Available to order | 1 |
| 3 | T3200662 Bolt, TX, Lghtd, M6 x 16, Slv | Bolt, TX, Lghtd, M6 x 16, Slv | 4 | $2.84 | Available to order | 4 |
| 4 | T3700705 Bushing, OD16 x ID7 | Bushing, OD16 x ID7 | 4 | $9.45 | Available to order | 4 |
| 5 | T3336102 Screw, S/Tap, HHF, 6 x 20, PT | Screw, S/Tap, HHF, 6 x 20, PT | 4 | $2.91 | Available to order | 4 |
