Handlebars, Upper Yoke & Mirrors
Parts (23)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2044787 Handlebar, ACF | Handlebar, ACF | 1 | $279.39 | Available to order | 1 |
| 2 | T2043246 Grip Assy, LHS | Grip Assy, LHS | 1 | $29.71 | Available to order | 1 |
| 3 | T2043232 Grip Assy, RHS | Grip Assy, RHS | 1 | $16.44 | Available to order | 1 |
| 4 | T2044808 Pad, Handlebar, Foam | Pad, Handlebar, Foam | 1 | $43.10 | Available to order | 1 |
| 5 | T2044809 Cover, Pad, Handlebar | Cover, Pad, Handlebar | 1 | $17.77 | Available to order | 1 |
| 6 | T2508286 Switchcube, Mode, LH | Switchcube, Mode, LH | 1 | $137.94 | Available to order | 1 |
| 7 | T2508408 Switchcube, RH | Switchcube, RH | 1 | $122.12 | Available to order | 1 |
| 8 | T2046694 Housing, Throttle Cable | Housing, Throttle Cable | 1 | $38.46 | Available to order | 1 |
| 9 | T2045276 Throttle Cable Assy | Throttle Cable Assy | 1 | $81.66 | Available to order | 1 |
| 10 | T3200881 Bolt, TX, Lghtd, M8 x 25, Slv | Bolt, TX, Lghtd, M8 x 25, Slv | 4 | $3.56 | Available to order | 4 |
| 11 | T2044314 Handlebar Clamp, Upper | Handlebar Clamp, Upper | 1 | $63.80 | Available to order | 1 |
| 12 | T2044920 Handlebar Clamp, Lower, Linked | Handlebar Clamp, Lower, Linked | 1 | $91.08 | Available to order | 1 |
| 13 | T3201101 Bolt, TX, M10 x 30, Enc | Bolt, TX, M10 x 30, Enc | 2 | $4.45 | Available to order | 2 |
| 14 | T2043230 Rubber, AV | Rubber, AV | 4 | $1.33 | Available to order | 4 |
| 15 | T2049349 Sleeve, AV | Sleeve, AV | 2 | $36.71 | Available to order | 2 |
| 16 | T2046411 Upper Yoke | Upper Yoke | 1 | $304.21 | Available to order | 1 |
| 17 | T3200886 Bolt, TX, Lghtd, M8 x 40, Slv | Bolt, TX, Lghtd, M8 x 40, Slv | 4 | $3.56 | Available to order | 4 |
| 18 | T3200889 Bolt, TX, Lghtd, M8 x 35, Enc | Bolt, TX, Lghtd, M8 x 35, Enc | 1 | $3.56 | Available to order | 1 |
| 19 | T3350850 Bolt, Flgd, M20 x 1.5 | Bolt, Flgd, M20 x 1.5 | 1 | $11.28 | Available to order | 1 |
| 21 | T2043618 Cam, Throttle Cable | Cam, Throttle Cable | 1 | $5.17 | Available to order | 1 |
| 22 | T3200663 Bolt, TX, Lghtd, M6 x 20, Slv | Bolt, TX, Lghtd, M6 x 20, Slv | 2 | $2.67 | Available to order | 2 |
| 23 | T2044357 Handlebar Grip Assembly Kit | Handlebar Grip Assembly Kit Contains items 2, 3 & 21 | 1 | $54.64 | Available to order | 1 |
| 24 | T3700212 Band, Rubber | Band, Rubber Not Illustrated | 3 | $3.29 | Available to order | 3 |
