Clutch Controls
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2045023 Clutch Master Cylinder, 10mm Dia | Clutch Master Cylinder, 10mm Dia | 1 | $187.28 | Available to order | 1 |
| 2 | T2022285 Clamp, Master Cylinder | Clamp, Master Cylinder | 1 | $11.21 | Available to order | 1 |
| 3 | T3200664 Bolt, TX, Lghtd, M6 x 25, Slv | Bolt, TX, Lghtd, M6 x 25, Slv | 2 | $3.56 | Available to order | 2 |
| 4 | T2043820 Clutch Hose Assembly | Clutch Hose Assembly | 1 | $70.44 | Available to order | 1 |
| 5 | T2043994 Guide, Clutch Hose | Guide, Clutch Hose | 1 | $2.46 | Available to order | 1 |
| 6 | T3200553 Bolt, TX, M5 x 16, Enc | Bolt, TX, M5 x 16, Enc | 2 | $2.09 | Available to order | 2 |
| 7 | T2045077 Slave Cylinder, Clutch | Slave Cylinder, Clutch | 1 | $115.43 | Available to order | 1 |
| 8 | T2043821 Gasket, Clutch Slave Cylinder | Gasket, Clutch Slave Cylinder | 1 | $1.22 | Available to order | 1 |
| 9 | T3200662 Bolt, TX, Lghtd, M6 x 16, Slv | Bolt, TX, Lghtd, M6 x 16, Slv | 2 | $2.67 | Available to order | 2 |
| 10 | T2043805 Banjo Bolt, Bleed, M8 x 18 | Banjo Bolt, Bleed, M8 x 18 | 1 | $8.44 | Available to order | 1 |
| 11 | T3550375 Washer, CU, 8.5 x 12 x 1 | Washer, CU, 8.5 x 12 x 1 | 2 | $1.78 | Available to order | 2 |
| 12 | T2022386 Kit, Anti-Bubble Kit | Kit, Anti-Bubble Kit | 1 | $23.08 | Available to order | 1 |
| 13 | T2043714 Reservoir Cap | Reservoir Cap | 1 | $26.45 | Available to order | 1 |
| 14 | T2044149 Kit, M/Cyl Piston | Kit, M/Cyl Piston | 1 | $62.16 | Available to order | 1 |
| 15 | T2043708 Clutch Lever | Clutch Lever | 1 | $61.56 | Available to order | 1 |
| 16 | T2043724 Lever Pin | Lever Pin Not Illustrated | 1 | $26.65 | Available to order | 1 |
| 17 | T2043754 Dust Cover | Dust Cover Not Illustrated | 1 | — | Unavailable | View Details |
| 18 | T2043757 Push Rod | Push Rod Not Illustrated | 1 | $44.40 | Available to order | 1 |
| 19 | T2043766 Spring Guide | Spring Guide | 1 | $17.77 | Available to order | 1 |
