Loading schematic...
Stands
Parts (10)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2082829 Sidestand Assembly, Spares | Sidestand Assembly, Spares | 1 | $142.22 | Available to order | 1 |
| 2 | T3750037 Bush, 121410 | Bush, 121410 | 2 | $6.83 | Available to order | 2 |
| 3 | T2082707 Magnet, Sidestand, Overmoulded | Magnet, Sidestand, Overmoulded | 1 | $23.76 | Available to order | 1 |
| 4 | T3050355 Screw, Cap/Hd, M5 x 16, Slv, Enc | Screw, Cap/Hd, M5 x 16, Slv, Enc | 1 | $0.59 | Available to order | 1 |
| 5 | T2084022 Pivot Pin Spares Kit | Pivot Pin Spares Kit | 1 | $14.80 | Available to order | 1 |
| 6 | T3500350 Circlip, E Type, Int Dia 9 | Circlip, E Type, Int Dia 9 | 1 | $3.55 | Available to order | 1 |
| 7 | T2081178 Sidestand Switch | Sidestand Switch | 1 | $68.42 | Available to order | 1 |
| 8 | T3330245 Bolt, C/Hd, Tx, M4 x 12, Slv, Enc | Bolt, C/Hd, Tx, M4 x 12, Slv, Enc | 2 | $11.79 | Available to order | 2 |
| 9 | T2082014 Peg, Spring Retainer | Peg, Spring Retainer | 1 | $10.71 | Available to order | 1 |
| 10 | T2083537 Spring, Sidestand | Spring, Sidestand | 1 | $11.12 | Available to order | 1 |
