Passenger Backrest 55072 »
Parts (15)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2300345 Upright | Upright LH | 1 | $413.67 | Out of Stock | Notify Me |
| 2 | T2300344 Upright | Upright RH | 1 | $413.67 | Out of Stock | Notify Me |
| 3 | T2300348 Passenger Backrest Pad | Passenger Backrest Pad | 1 | $27.00 | Obsolete | View Details |
| 4 | T3010290 Sleeve | Sleeve | 4 | $12.05 | Available to order | 4 |
| 5 | T3330543 Screw | Screw M8 | 4 | $9.77 | Available to order | 4 |
| 6 | T3750032 Grommet | Grommet | 4 | $1.10 | Obsolete | View Details |
| 7 | T2300432 Back plate assembly | Back plate assembly | 1 | $230.04 | Out of Stock | Notify Me |
| 8 | T2300433 Blanking plug | Blanking plug | 4 | $0.90 | Obsolete | View Details |
| 9 | T3330550 Screw M6 x 16, S/S, Large HD | Screw M6 x 16, S/S, Large HD M6 x 12mm - * PART NO LONGER AVAILABLE * | 4 | $3.23 | Obsolete | View Details |
| 10 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv M6 x 16mm | 4 | $3.50 | Available to order | 4 |
| 11 | T3550405 Washer, M8 x 17 x 1.6 | Washer, M8 x 17 x 1.6 | 4 | $0.89 | Available to order | 4 |
| 12 | A9905000 Warning label | Warning label | 1 | — | Unavailable | View Details |
| 13 | T2300346 Backplate | Backplate | 1 | $160.15 | Obsolete | View Details |
| 14 | T2300347 Badge | Badge | 1 | $37.00 | Obsolete | View Details |
| 15 | T3300091 Rivet | Rivet **PART NO LONGER AVAILABLE** | 2 | $0.49 | Obsolete | View Details |
