Bodywork
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2303420-PC Side panel lh | Side panel lh Black | 1 | $207.54 | Obsolete | View Details |
| 1 | T2303420-KE Side panel lh | Side panel lh Violet | 1 | $207.54 | Obsolete | View Details |
| 1 | T2303420-GC Side panel lh | Side panel lh Gold | 1 | $207.54 | Obsolete | View Details |
| 1 | T2303420-EC Side panel lh | Side panel lh Amber | 1 | $207.54 | Obsolete | View Details |
| 1 | T2303420-JK Side panel lh | Side panel lh Turquoise | 1 | $207.54 | Obsolete | View Details |
| 1 | T2303420-TC Side panel lh | Side panel lh Aubergine | 1 | $207.54 | Obsolete | View Details |
| 1 | T2303420-PG Side panel lh | Side panel lh Jet Black | 1 | $197.66 | Obsolete | View Details |
| 2 | T2303422-PC Side panel rh | Side panel rh Black | 1 | $221.01 | Obsolete | View Details |
| 2 | T2303422-KE Side panel rh | Side panel rh Violet | 1 | $221.01 | Obsolete | View Details |
| 2 | T2303422-GC Side panel rh | Side panel rh Gold | 1 | $221.01 | Obsolete | View Details |
| 2 | T2303422-EC Side panel rh | Side panel rh Amber | 1 | $221.01 | Obsolete | View Details |
| 2 | T2303422-JK Side panel rh | Side panel rh Turquoise | 1 | $221.01 | Obsolete | View Details |
| 2 | T2303422-TC Side panel rh | Side panel rh Aubergine | 1 | $221.01 | Obsolete | View Details |
| 2 | T2303422-PG Side panel rh | Side panel rh Jet Black | 1 | $197.66 | Obsolete | View Details |
| 3 | T3900068 Badge | Badge | 2 | $50.50 | Obsolete | View Details |
| 4 | T3350010 Locknut, Flgd, M5 | Locknut, Flgd, M5 M5 | 4 | $2.40 | Available to order | 4 |
| 5 | T3660138 Seal, Seat Lock, 0.9mm | Seal, Seat Lock, 0.9mm | 1 | $1.61 | Available to order | 1 |
| 6 | T3020121 Grommet, 13 x 1 x 6.2 | Grommet, 13 x 1 x 6.2 | 4 | $2.14 | Available to order | 4 |
| 7 | T3020082 Grommet, 18 x 1 x 9 | Grommet, 18 x 1 x 9 | 2 | $7.21 | Available to order | 2 |
| 8 | T3010707 Sleeve, Flanged, 6.4 x 10 x 6.5 | Sleeve, Flanged, 6.4 x 10 x 6.5 | 2 | $3.82 | Available to order | 2 |
| 9 | T3330727 Screw, But/Hd, M6 x 20, Slv | Screw, But/Hd, M6 x 20, Slv | 2 | $3.61 | Available to order | 2 |
| 10 | T2201389 Airbox Cover, LH, Chromed, RT | Airbox Cover, LH, Chromed, RT | 1 | $142.43 | Obsolete | View Details |
| 11 | T2201388 Airbox Cover, RH, Chromed, RT | Airbox Cover, RH, Chromed, RT | 1 | $142.43 | Obsolete | View Details |
| 12 | T3900083 Badge | Badge | 2 | $30.00 | Obsolete | View Details |
| 13 | T3330550 Screw M6 x 16, S/S, Large HD | Screw M6 x 16, S/S, Large HD M6 x 12mm - * PART NO LONGER AVAILABLE * | 4 | $3.44 | Obsolete | View Details |
