Swinging Arm
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2056771 Swinging arm assembly | Swinging arm assembly » 55071 Includes bearings etc - Black | 1 | $1173.17 | Obsolete | View Details |
| 1 | T2056713 Swinging arm assembly | Swinging arm assembly 55072 » Long extension Black - Includes Bearings etc | 1 | $1173.17 | Obsolete | View Details |
| 2 | 3450007-T0301 Grease nipple | Grease nipple | 2 | $1.91 | Out of Stock | Notify Me |
| 3 | 3450008-T0301 Grease cap | Grease cap * PART NO LONGER AVAILABLE * | 2 | $1.37 | Obsolete | View Details |
| 4 | 3450190-T0301 End cap | End cap | 2 | $0.96 | Obsolete | View Details |
| 5 | 2056002-T0301 Spindle | Spindle | 1 | $106.30 | Obsolete | View Details |
| 6 | T3555032 Washer, 17 x 30 x 3 | Washer, 17 x 30 x 3 M14 | 1 | $3.17 | Available to order | 1 |
| 7 | 2056001-T0301 Bolt special | Bolt special » 37993 | 1 | $30.30 | Obsolete | View Details |
| 7 | T2056020 Bolt special | Bolt special 37994 » | 1 | $28.29 | Obsolete | View Details |
| 8 | T3800014 Roller bearing | Roller bearing | 4 | $14.32 | Available to order | 4 |
| 9 | T2056994 Plug | Plug | 2 | $23.40 | Obsolete | View Details |
| 10 | 2056970-T0301 Shim | Shim PART NO LONGER AVAILABLE | 4 | $1.92 | Obsolete | View Details |
| 11 | T2056008 Thrust Seal | Thrust Seal | 4 | $11.80 | Obsolete | View Details |
| 12 | 2056960-T0301 Sleeve | Sleeve PART NO LONGER AVAILABLE | 2 | $26.85 | Obsolete | View Details |
| 13 | T2056760 Rubbing strip | Rubbing strip PART NO LONGER AVAILABLE | 1 | $58.09 | Obsolete | View Details |
| 14 | T3331041 Screw, Pan/Hd, Tx, M6 x 25, Enc | Screw, Pan/Hd, Tx, M6 x 25, Enc | 2 | $1.06 | Available to order | 2 |
| 15 | T3555004 Washer, 6.4 x 14 x 1.6 | Washer, 6.4 x 14 x 1.6 | 1 | $1.40 | Available to order | 1 |
| 16 | T3010144 Flanged Sleeve, M6 x 9.5 x 10.5 | Flanged Sleeve, M6 x 9.5 x 10.5 | 1 | $3.77 | Available to order | 1 |
| 17 | 3000020-T0301 Spacer | Spacer PART NO LONGER AVAILABLE | 1 | $0.51 | Obsolete | View Details |
| 18 | T3203204 Screw, H/Hd, M8 x 55, Slv | Screw, H/Hd, M8 x 55, Slv | 2 | $2.34 | Available to order | 2 |
| 19 | T3350303 Nut, M8, Silver | Nut, M8, Silver | 2 | $0.81 | Backorder — Early August 2026 | 2 |
| 20 | T3450009 Plug, M6 | Plug, M6 | 1 | $3.24 | Available to order | 1 |
| 21 | T3900092 Label, Chain & Tyres | Label, Chain & Tyres | 1 | $5.69 | Available to order | 1 |
| 22 | T3350042 Riv nut | Riv nut Round | — | $3.52 | Obsolete | View Details |
| 23 | T3900131 Label | Label Catalytic convertor DE | 1 | $4.76 | Obsolete | View Details |
